Siemens 7KE9000-3AL02-8AA0
SICAM PQS - Bundle RT large incl
- MPN
- 7KE9000-3AL02-8AA0
- Category
- Bundles
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 7KE9000-3AL02-8AA0?
SICAM PQS - Bundle RT large incl. IEC61850 client, monitoring direction, 2 PQ applications; download; software, documentation and license(s) for download. Specification of an email address (consignee) for delivery is essential .
Specifications
General technical data
| target system | SICAM PQ devices (P855, Q100, Q200), 7KE85 fault recorder, protection devices |
| national language / of the software | German / English |
Product details
| product description | power quality system |
Model
| product designation | SICAM PQS - base module |
Power Quality functions
| power quality assessment function / PQ Grid Code Evaluation according to EN 50160 | Yes |
| power quality assessment function / PQ Grid Code Evaluation according to IEC/TS 62749 | Yes |
| power quality assessment function / PQ Grid Code Evaluation according to IEC 61000-2-4 | Yes |
| power quality assessment function / PQ Grid Code Evaluation with regard to customized PQ grid codes | Yes |
| power quality assessment function / detecting and visualization of voltage fluctuations | Yes |
| power quality assessment function / evaluation of line frequency | Yes |
| power quality assessment function / evaluation of voltage of harmonic component | Yes |
| power quality assessment function / evaluation of the voltage unbalance / according to IEC 61000-4-30, Class S | Yes |
| power quality assessment function / evaluation of flickering | Yes |
| power quality assessment function / evaluation of voltage events | Yes |
| power quality assessment function / evaluation of PQ status and PQ index | Yes |
Product Functions
| user interface info texts can be translated into any national language | Yes |
| Unicode support for process data | Yes |
| diagnostics function | Yes |
| communication function | Yes |
| project planning function | Yes |
| evaluation function | No |
| parameterizing function | Yes |
| automatic scanning and detection of PQ devices in the network | Yes |
| querying and storing of PQDIF files with IEC 61850 | Yes |
| querying/read-in of PQDIF files from hard disk | No |
| querying and storing of fault records via IEC 61850 | Yes |
| querying and storing of fault records via FTP | Yes |
| querying and storing of fault records via SIPROTEC 4 service interface | Yes |
| detection of cause of malfunction | Yes |
| local storage of the PQDIF files | Yes |
| automatic report recording | Yes |
| scheduled reports | Yes |
| evaluation of fault records | Yes |
| fault location (with regard to fault records) | Yes |
| parameterization of PQ devices | No |
| automatic reading in of PQDIF files (from third-party devices) | Yes |
| automatic data export from COMTRADE files (fault records) | Yes |
| automatic data export from reports | Yes |
| notification via SMS/email | Yes |
| storing of events in the archive | Yes |
| forwarding of operating data (messages, measured values) to HMI SICAM SCC, forwarding with SIMATIC WinCC | Yes |
| forwarding of operating data (messages, measured values) to control centers via telecontrol protocols | Yes |
| time synchronization for connected devices | Yes |
Display and operation
| horizontal image resolution / of the graphics card | 1 280 pixel |
| vertical image resolution / of the graphics card | 1 024 pixel |
Requirements
| number of colors / of the graphics card | 65 536 |
| design of the drive/storage medium / required / DVD drive | No |
| operating system / usable / Windows 7 | Yes |
| operating system / usable / Windows 10 | Yes |
| operating system / usable / Windows 2012 Server | Yes |
| operating system / usable / Windows 2016 Server | Yes |
| operating system / usable / Windows Server 2019 | Yes |
| processor clock frequency / minimum | 2 GHz |
| storage capacity / on hard disk / required | 100 Gbyte |
| storage capacity / of the main memory or RAM / minimum | 16 Gbyte |
Cybersecurity
| type of access control / role-based access control (RBAC) | Yes |
| product function / firmware identifier | Yes |
| cybersecurity / secure communication | Yes |
| cybersecurity / data integrity | Yes |
Time synchronization
| type of time synchronization | SNTP |
