Siemens 6ES7400-2JA10-0AA1
SIMATIC PCS 7-400, UR2-H XTR S7-400 rack central and distributed with 2 x 9 slots
- MPN
- 6ES7400-2JA10-0AA1
- Category
- CPU & Controllers
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 6ES7400-2JA10-0AA1?
SIMATIC PCS 7-400, UR2-H XTR S7-400 rack central and distributed with 2 x 9 slots, 2 x 2 redundant PS can be plugged in for extended temperature range and with conformal coating
Specifications
General information
| Product type designation | UR2-H XTR |
| Rack design | With Conformal Coating (ISA-S71.04 severity level G1; G2; G3) and operating temperature to 70 °C |
Hardware configuration
| Rack — Communication bus | Yes; Separated |
| Rack — P bus | Yes; Separated |
| Slots — Number of slots | 18; 2 segments with 9 slots each |
Standards, approvals, certificates
| CE mark | Yes |
| UKCA mark | Yes |
| UL approval | Yes |
| FM approval | Yes |
| RCM (formerly C-TICK) | Yes |
| KC approval | Yes |
| EAC (formerly Gost-R) | Yes |
| CCC | Yes |
Ambient conditions
| Ambient temperature during operation — min. | 0 °C |
| Ambient temperature during operation — max. | 70 °C |
| Ambient temperature during storage/transportation — min. | 0 °C |
| Ambient temperature during storage/transportation — max. | 70 °C |
Mechanics/material
| rack profile material | aluminum |
Dimensions
| Width | 482.5 mm |
| Height | 290 mm |
| Depth | 27.5 mm |
Weights
| Weight, approx. | 3 kg |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
6ES7400-2JA10-0AA1: frequently asked questions
When can 6ES7400-2JA10-0AA1 be shipped?
6ES7400-2JA10-0AA1 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 6ES7400-2JA10-0AA1 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 6ES7400-2JA10-0AA1 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6ES7400-2JA10-0AA1, subject to availability and destination.
