Siemens 6EP1933-2NC01

SITOP UPS500P/DC/24VDC/7A/5KWS/IP65 Spare part: SITOP UPS500P maintenance-free uninterruptible power supply…

MPN: 6EP1933-2NC01
Category: Power Supplies

Price and lead time confirmed within 1 business day

Discontinued by Siemens — we can still source the original 6EP1933-2NC01 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Siemens 6EP1933-2NC01?

SITOP UPS500P/DC/24VDC/7A/5KWS/IP65 ********** spare part ********* SITOP UPS500P maintenance-free uninterruptible power supply with USB interface basic device 5 kWs input: 24 V DC output: 24 V DC/7 A degree of protection IP65

Specifications

General information

Technical Product Detail Page	https://i.siemens.com/1P6EP1933-2NC01
product brand name	SITOP UPS500P
type of current supply	Basic unit 5 kWs

input

voltage curve at input	DC
supply voltage at DC rated value	24 V
input voltage at DC	22.5 ... 29 V
adjustable response value voltage for buffer connection preset	22.5 V
adjustable response value voltage for buffer connection	permanently set
input current at rated input voltage 24 V rated value	7 A; + approx. 2 A with empty energy storage (capacitor)

memory

type of energy storage	with capacitors
product function DC-UPS modularly expandable	No
design of the mains power cut bridging-connection	7 A for 49 s or 5 A for 68 s or 3 A for 108 s or 1 A for 351 s
buffering time in the event of power failure	0.35 min
energy content of energy storage	5 kW.s

output

output voltage — in normal operation at DC rated value	24 V
output voltage — in buffering mode at DC rated value	24 V
formula for output voltage	24 V ± 3 %
startup delay time typical	0.6 s
voltage increase time of the output voltage typical	25 ms
output voltage in buffering mode at DC	24 ... 24.7 V
output current — rated value	7 A
output current — in normal operation	0 ... 7 A
output current — in buffering mode	0 ... 7 A
peak current	22.5 A
charging current	2 A

efficiency

efficiency in percent — at rated output voltage for rated value of the output current typical	96.5 %
power loss [W] — at rated output voltage for rated value of the output current typical	5.2 W
supplied active power typical	168 W

protection and monitoring

product function — reverse polarity protection against energy storage unit polarity reversal	Yes
product function — reverse polarity protection against input voltage polarity reversal	Yes
display version — for normal operation	Normal operation: LED green (OK); Lack of buffer standby: LED red (ALARM); Energy storage > 85%: LED green (CAP. > 85%)
display version — in buffering mode	Buffered mode: LED yellow (BAT); Prewarning buffer end after expiry of 80% of the available buffer time: LED red (ALARM); Energy storage > 85%: LED green (CAP. > 85%)

interfaces

product component PC interface	Yes
product function communication function	No
design of the interface	USB

safety

galvanic isolation between input and output	No
operating resource protection class	Class III
protection class IP	IP65
standard — for emitted interference	EN 55022 Class B
standard — for interference immunity	EN 61000-6-2

standards, specifications, approvals

certificate of suitability — CE marking	Yes
certificate of suitability — UL approval	No
certificate of suitability — EAC approval	Yes
MTBF at 40 °C	500 000 h

standards, specifications, approvals marine classification

shipbuilding approval	No
Marine classification association — Det Norske Veritas (DNV)	No

ambient conditions

ambient temperature — during operation	0 ... 55 °C; with natural convection
ambient temperature — during transport	-40 ... +70 °C
ambient temperature — during storage	-40 ... +70 °C
environmental category according to IEC 60721	Climate class 3K3, 5 ... 95% no condensation

connection method

type of electrical connection	Plug-in connection
at input	via connector set
at output	via connector set

mechanical data

width × height × depth of the enclosure	400 × 80 × 80 mm
installation width × mounting height	530 mm × 80 mm
required spacing — left	0 mm
required spacing — right	0 mm
fastening method	Screw mounting
DIN-rail mounting	No
S7 rail mounting	No
wall mounting	Yes
housing can be lined up	No
net weight	1.9 kg

accessories

electrical accessories

Connector set

further information internet links

internet link — to website: Industry Online Support

https://support.industry.siemens.com

additional information

other information

Specifications at rated input voltage and ambient temperature +25 °C (unless otherwise specified)

security information

Siemens provides products and solutions with industrial cybersecurity functions that support the secure operation of plants, systems, machines and networks. In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement - and continuously maintain - a holistic, state-of-the-art industrial cybersecurity concept. Siemens’ products and solutions constitute one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks. Such systems, machines and components should only be connected to an enterprise network or the internet if and to the extent such a connection is necessary and only when appropriate security measures (e.g. firewalls and/or network segmentation) are in place. For additional information on industrial cybersecurity measures that may be implemented, please visit www.siemens.com/cybersecurity-industry. Siemens’ products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customer’s exposure to cyber threats. To stay informed about product updates, subscribe to the Siemens Industrial Cybersecurity RSS Feed under https://www.siemens.com/cert. (V4.7)

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet 6EP1933-2NC01PDF
