Siemens 5SE2280

NEOZED fuse-link, D03, 80 A, gG, Un AC: 400 V, Un DC: 250 V

MPN
5SE2280
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Siemens parts? We buy surplus →

What is the Siemens 5SE2280?

NEOZED fuse-link, D03, 80 A, gG, Un AC: 400 V, Un DC: 250 V

Specifications

Model

product brand nameSENTRON
product designationNEOZED fuse link
product versionPack of 10
design of the fuse linkNEOZED fuse link

General technical data

size of fuse system according to EN 60269-1D03
operating class of the fuse linkgG

Supply voltage

supply voltage — at AC400 V
supply voltage — at DC250 V
operating voltage rated value400 V
protection class IPIP20, with connected conductors
switching capacity current according to IEC 60947-2 rated value50 kA

Dissipation

power loss [W] for rated value of the current at AC in hot operating state per pole5.4 W

Main circuit

operational current rated value80 A

Appearance

color coding of the fuse linkBlue
maximum short-circuit current breaking capacity (Icu) at AC rated value50 kA

Mechanical Design

mounting positionAny, preferably vertical
Net Weight39 g
ambient temperature during operation — minimum-25 °C
ambient temperature during operation — maximum40 °C
environmental categoryUp to 45°C at 95 % rel. humidity

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

5SE2280: frequently asked questions

When can 5SE2280 be shipped?

5SE2280 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 5SE2280 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 5SE2280 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5SE2280, subject to availability and destination.
