NEOZED Fuse Links Parts

Showing 1–7 of 7 parts
Siemens 5SE2310 – NEOZED fuse-link, D01, 10 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps
Siemens
5SE2310

NEOZED fuse-link, D01, 10 A, gG, Un AC: 400 V, Un DC: 250 V

Siemens 5SE2306 – NEOZED fuse-link, D01, 6 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps
Siemens
5SE2306

NEOZED fuse-link, D01, 6 A, gG, Un AC: 400 V, Un DC: 250 V

Siemens 5SE2304 – NEOZED fuse-link, D01, 4 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps
Siemens
5SE2304

NEOZED fuse-link, D01, 4 A, gG, Un AC: 400 V, Un DC: 250 V

Siemens 5SE2302 – NEOZED fuse-link, D01, 2 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps
Siemens
5SE2302

NEOZED fuse-link, D01, 2 A, gG, Un AC: 400 V, Un DC: 250 V

Siemens 5SE2300 – NEOZED fuse-link, D03, 100 A, gG, Un AC: 400 V, Un DC: 250 V
Siemens
5SE2300

NEOZED fuse-link, D03, 100 A, gG, Un AC: 400 V, Un DC: 250 V

Siemens 5SE2280 – NEOZED fuse-link, D03, 80 A, gG, Un AC: 400 V, Un DC: 250 V
Siemens
5SE2280

NEOZED fuse-link, D03, 80 A, gG, Un AC: 400 V, Un DC: 250 V

Siemens 5SE2013-2A – NEOZED fuse-link, D01, 13 A, gG, Un AC: 400 V, Un DC: 250 V, with tin-coated contact-caps
Siemens
5SE2013-2A

NEOZED fuse-link, D01, 13 A, gG, Un AC: 400 V, Un DC: 250 V

Compare NEOZED Fuse Links

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPNsize of fuse system according to EN 60269-1power loss [W] for rated value of the current at AC in hot operating state per poleoperational current rated valuecolor coding of the fuse linkNet Weight
5SE2310D011 W10 ARed7 g
5SE2306D011.4 W6 AGreen6 g
5SE2304D011.3 W4 ABrown6 g
5SE2302D011.8 W2 APink6 g
5SE2300D036.3 W100 ARed43 g
5SE2280D035.4 W80 ABlue39 g
5SE2013-2AD011.5 W13 ABlack7 g

Common to all listed parts

product designationNEOZED fuse link
product versionPack of 10
design of the fuse linkNEOZED fuse link
operating class of the fuse linkgG
supply voltage — at AC400 V
supply voltage — at DC250 V
operating voltage rated value400 V
protection class IPIP20, with connected conductors
