Siemens 3WA9111-0AF06
Accessory 3WA/3WL Charging Motor (M) 208-240 V AC / 220-250 V DC
- MPN
- 3WA9111-0AF06
- Category
- 3WA1 Accessories and Spare Parts
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 3WA9111-0AF06?
Accessory 3WA/3WL Charging Motor (M) 208-240 V AC / 220-250 V DC
Specifications
Model
| product brand name | SENTRON |
| product designation | Motorized operating mechanism |
| design of the product | MO spring charging motor |
| operating apparent power [VA] | 135 VA |
| electrical endurance (operating cycles) | 30 000 |
| operating frequency maximum | 60 1/h |
| time for clamping of the spring energy store with control supply voltage (Us) | 10 s |
| control supply voltage at DC rated value maximum | 250 V |
| design of the DIAZED fuse link gG for short-circuit protection minimum permissible | 2 A (fuse gG: 2 A, miniature circuit breaker C characteristic: 2 A) |
| Net Weight | 1.659 kg |
| ambient temperature during operation — minimum | -40 °C |
| ambient temperature during operation — maximum | 70 °C |
| ambient temperature during storage — minimum | -40 °C |
| ambient temperature during storage — maximum | 80 °C |
