Siemens 3WA9111-0AF05
Accessory 3WA/3WL Charging Motor (M) 110-127 V AC / 110-125 V DC
- MPN
- 3WA9111-0AF05
- Category
- 3WA1 Accessories and Spare Parts
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 3WA9111-0AF05?
Accessory 3WA/3WL Charging Motor (M) 110-127 V AC / 110-125 V DC
Specifications
Model
| product brand name | SENTRON |
| product designation | Motorized operating mechanism |
| design of the product | MO spring charging motor |
| operating apparent power [VA] | 135 V·A |
| electrical endurance (operating cycles) | 30 000 |
| operating frequency maximum | 60 1/h |
| time for clamping of the spring energy store with control supply voltage (Us) | 10 s |
| control supply voltage at DC rated value maximum | 125 V |
| design of the DIAZED fuse link gG for short-circuit protection minimum permissible | 2 A (fuse gG: 2 A, miniature circuit breaker C characteristic: 2 A) |
| Net Weight | 1.643 kg |
| ambient temperature during operation — minimum | -40 °C |
| ambient temperature during operation — maximum | 70 °C |
| ambient temperature during storage — minimum | -40 °C |
| ambient temperature during storage — maximum | 80 °C |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
3WA9111-0AF05: frequently asked questions
When can 3WA9111-0AF05 be shipped?
3WA9111-0AF05 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3WA9111-0AF05 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3WA9111-0AF05 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3WA9111-0AF05, subject to availability and destination.
