Siemens 3TC5617-5KB4-Z B01 – Contactor, DC-3/DC-5, 400 A, 2-pole, 24 V DC, with varistor

Name: Siemens 3TC5617-5KB4-Z B01 – Contactor, DC-3/DC-5, 400 A, 2-pole, 24 V DC, with varistor
Brand: Siemens
SKU: 3TC5617-5KB4-Z B01

MPN: 3TC5617-5KB4-Z B01 · Brand: Siemens

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	23.79 kg
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can 3TC5617-5KB4-Z B01 be shipped?

3TC5617-5KB4-Z B01 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3TC5617-5KB4-Z B01 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3TC5617-5KB4-Z B01 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3TC5617-5KB4-Z B01, subject to availability and destination.

contactor, DC-3/DC-5, 400 A, 2-pole, 24 V DC, with varistor, auxiliary contacts: 2 NO + 2 NC, connecting bar, frame size 12, upright mounting position

Specifications

General technical data

size of contactor	12
product extension – function module for communication	No
product extension – auxiliary switch	No
insulation voltage rated value	1 000 V
maximum permissible voltage for protective separation between coil and main contacts according to EN 60947-1	660 V
shock resistance at rectangular impulse – at DC	12 g / 5 ms, 5,6 g / 10 ms
mechanical service life (operating cycles) – of contactor typical	10 000 000
mechanical service life (operating cycles) – of the contactor with added auxiliary switch block typical	10 000 000
reference code according to IEC 81346-2	Q
Substance Prohibitance (day/month/year)	03/01/2017
SVHC substance name	Lead CAS-No. 7439-92-1
Net Weight	21.385 kg

Ambient conditions

ambient temperature – during operation	-25 ... +55 °C
ambient temperature – during storage	-50 ... +80 °C
relative humidity minimum	10 %
relative humidity at 55 °C according to IEC 60068-2-30 maximum	95 %

Main circuit

number of poles	2
number of poles for main current circuit	2
number of NO contacts for main contacts	2
number of NC contacts for main contacts	0
type of voltage	DC
at 1 current path at DC-1 – — at 24 V rated value	400 A
at 1 current path at DC-1 – — at 110 V rated value	400 A
at 1 current path at DC-1 – — at 220 V rated value	400 A
with 2 current paths in series at DC-1 – — at 24 V rated value	400 A
with 2 current paths in series at DC-1 – — at 110 V rated value	400 A
with 2 current paths in series at DC-1 – — at 220 V rated value	400 A
with 2 current paths in series at DC-1 – — at 440 V rated value	400 A
with 2 current paths in series at DC-1 – — at 600 V rated value	400 A
with 2 current paths in series at DC-1 – — at 750 V rated value	400 A
at DC-3 at DC-5 – — at 220 V rated value	400 A
at DC-3 at DC-5 – — at 600 V rated value	400 A
at DC-3 at DC-5 – — at 750 V rated value	400 A
at 1 current path at DC-3 at DC-5 – — at 24 V rated value	220 A
at 1 current path at DC-3 at DC-5 – — at 110 V rated value	220 A
at 1 current path at DC-3 at DC-5 – — at 220 V rated value	400 A
with 2 current paths in series at DC-3 at DC-5 – — at 24 V rated value	400 A
with 2 current paths in series at DC-3 at DC-5 – — at 110 V rated value	400 A
with 2 current paths in series at DC-3 at DC-5 – — at 220 V rated value	400 A
with 2 current paths in series at DC-3 at DC-5 – — at 440 V rated value	400 A
with 2 current paths in series at DC-3 at DC-5 – — at 600 V rated value	400 A
with 2 current paths in series at DC-3 at DC-5 – — at 750 V rated value	400 A
at DC-1 – — at 110 V rated value	44 kW
at DC-1 – — at 220 V rated value	88 kW
at DC-1 – — at 440 V rated value	176 kW
at DC-1 – — at 750 V rated value	300 kW
at DC-3 at DC-5 – — at 110 V rated value	35 kW
at DC-3 at DC-5 – — at 220 V rated value	70 kW
at DC-3 at DC-5 – — at 440 V rated value	140 kW
at DC-3 at DC-5 – — at 600 V rated value	200 kW
at DC-3 at DC-5 – — at 750 V rated value	250 kW
operating frequency – at DC-1 maximum	1 000 1/h
operating frequency – at DC-3 maximum	600 1/h
operating frequency – at DC-5 maximum	600 1/h

Control circuit/ Control

type of voltage of the control supply voltage	DC
control supply voltage at DC rated value	24 V
design of the surge suppressor	with varistor
closing power of magnet coil at DC	86 W
holding power of magnet coil at DC	86 W
closing delay at DC	110 ... 400 ms
opening delay at DC	40 ... 110 ms
arcing time	20 ... 30 ms

Auxiliary circuit

number of NC contacts for auxiliary contacts	2
instantaneous contact	2
number of NO contacts for auxiliary contacts	2
instantaneous contact	2
number of CO contacts for auxiliary contacts	0
identification number and letter for switching elements	22
operational current at AC-12 maximum	10 A
operational current at AC-15 – at 230 V rated value	5.6 A
operational current at AC-15 – at 400 V rated value	3.6 A
operational current at AC-15 – at 500 V rated value	2.5 A
operational current at DC-12 – at 24 V rated value	10 A
operational current at DC-12 – at 48 V rated value	10 A
operational current at DC-12 – at 60 V rated value	10 A
operational current at DC-12 – at 110 V rated value	8 A
operational current at DC-12 – at 125 V rated value	6 A
operational current at DC-12 – at 220 V rated value	2 A
operational current at DC-12 – at 600 V rated value	0.4 A
operational current at DC-13 – at 24 V rated value	10 A
operational current at DC-13 – at 48 V rated value	5 A
operational current at DC-13 – at 60 V rated value	5 A
operational current at DC-13 – at 110 V rated value	2.4 A
operational current at DC-13 – at 125 V rated value	2.1 A
operational current at DC-13 – at 220 V rated value	1.1 A
operational current at DC-13 – at 600 V rated value	0.21 A

UL/CSA ratings

contact rating of auxiliary contacts according to UL

A600 / P600

Short-circuit protection

for short-circuit protection of the main circuit – — with type of coordination 1 required	2 x 3NE1330-4D (315 A) parallel (750 V, 12 kA)
for short-circuit protection of the main circuit – — with type of coordination 2 required	2 x 3NE1330-4D (315 A) parallel (750 V, 12 kA)
for short-circuit protection of the main circuit – for short-circuit protection of the auxiliary switch required	gG: 16 A (500 V, 1 kA)

Installation/ mounting/ dimensions

mounting position	+/-22,5° rotation possible on vertical mounting surface; can be tilted forward and backward by +/- 22.5° on vertical mounting surface
fastening method side-by-side mounting	Yes
fastening method	screw fixing
height	281 mm
width	185 mm
depth	314 mm
with side-by-side mounting – — forwards	25 mm
with side-by-side mounting – — backwards	0 mm
with side-by-side mounting – — upwards	10 mm
with side-by-side mounting – — downwards	10 mm
with side-by-side mounting – — at the side	10 mm
for grounded parts – — forwards	100 mm
for grounded parts – — backwards	0 mm
for grounded parts – — upwards	10 mm
for grounded parts – — at the side	10 mm
for grounded parts – — downwards	10 mm
for live parts – — forwards	100 mm
for live parts – — backwards	0 mm
for live parts – — upwards	10 mm
for live parts – — downwards	10 mm
for live parts – — at the side	10 mm

Connections/ Terminals

type of electrical connection	screw terminal
for main current circuit	screw-type terminals
for auxiliary and control circuit	screw-type terminals
for auxiliary contacts – — solid or stranded	2x (1 ... 2.5 mm²)
for auxiliary contacts – — finely stranded with core end processing	2x (0.75 ... 1.5 mm²)

Safety related data

product function mirror contact according to IEC 60947-4-1	Yes
protection class IP on the front according to IEC 60529	IP00; IP20 with box terminal/cover
touch protection on the front according to IEC 60529	finger-safe, for vertical contact from the front with cover
