Siemens 3SU1400-1GC10-1AA0
Electronics module for ID key-operated switch, black, Operating voltage 24 V DC, group ID, screw terminal
- MPN
- 3SU1400-1GC10-1AA0
- Category
- Modules
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Siemens 3SU1400-1GC10-1AA0?
Electronics module for ID key-operated switch, black, Operating voltage 24 V DC, group ID, screw terminal, for front plate mounting
Specifications
Actuator
| product extension optional light source | No |
Contact block/ lampholder
| socket design | other |
Display
| number of LEDs | 4 |
General technical data
| insulation voltage rated value | 30 V |
| degree of pollution | 3 |
| type of voltage – of the operating voltage | DC |
| type of voltage – of the input voltage | DC |
| surge voltage resistance rated value | 0.8 kV |
| consumed current maximum | 49 mA |
| protection class IP | IP20, clamping screw tightened |
| reference code according to IEC 81346-2 | P |
| Substance Prohibitance (day/month/year) | 10/01/2014 |
| SVHC substance name | Lead CAS-No. 7439-92-1 Lead monoxide (lead oxide) CAS-No. 1317-36-8 2-methyl-1-(4-methylthiophenyl)-2-morpholinopropan-1-one CAS-No. 71868-10-5 Melamine CAS-No. 108-78-1 |
| Net Weight | 45.38 g |
| operating voltage – rated value | 18 ... 30 V |
| operating voltage – at DC rated value | 24 V |
| operating voltage 1 at DC rated value | 24 V |
Communication/ Protocol
| protocol is supported IO-Link protocol | No |
Auxiliary circuit
| number of NC contacts for auxiliary contacts | 0 |
| number of NO contacts for auxiliary contacts | 5 |
Inputs/ Outputs
| number of digital inputs | 0 |
| safety-related | 0 |
| number of digital outputs | 5 |
| output voltage at digital output at DC rated value | 23.5 V |
| output current per output | 250 mA |
Connections/ Terminals
| type of electrical connection | screw terminal |
| type of connectable conductor cross-sections – solid without core end processing | 1x (0.2 ... 2.5 mm²) |
| type of connectable conductor cross-sections – finely stranded with core end processing | 1x (0.25 ... 1.5 mm²), 2x (0.5 ... 0.75 mm²) |
| type of connectable conductor cross-sections – finely stranded without core end processing | 1x (0.2 ... 2.5 mm²), 2x (0.2 ... 0.75 mm²) |
| type of connectable conductor cross-sections – for AWG cables | 1x (26 ... 14) |
| tightening torque with screw-type terminals | 0.4 N·m |
Product Function
| product function parameterizable | No |
Safety related data
| MTBF – at 70 °C | 138 a |
| MTBF – at full load at 25 °C | 141 a |
| touch protection against electrical shock | finger-safe |
Ambient conditions
| ambient temperature – during operation | -25 ... +70 °C |
| ambient temperature – during storage | -40 ... +80 °C |
| environmental category during operation according to IEC 60721 | 3M6, 3S2, 3B2, 3K6 (with relative air humidity of 10 ... 95%, no condensation in operation permitted) |
Installation/ mounting/ dimensions
| fastening method | front plate mounting |
| of modules and accessories | Front plate mounting |
| height | 36 mm |
| width | 50 mm |
| depth | 36.4 mm |
| required spacing with side-by-side mounting – forwards | 100 mm |
| required spacing with side-by-side mounting – backwards | 100 mm |
| required spacing with side-by-side mounting – upwards | 100 mm |
| required spacing with side-by-side mounting – downwards | 100 mm |
| required spacing with side-by-side mounting – at the side | 100 mm |
Measuring circuit
| product function | Group ID 24 V DC |
Environmental footprint
| Environmental Product Declaration(EPD) | Yes |
| global warming potential [CO2 eq] total | 0.787 kg |
| global warming potential [CO2 eq] during manufacturing | 0.566 kg |
| global warming potential [CO2 eq] during operation | 0.235 kg |
| global warming potential [CO2 eq] after end of life | -0.015 kg |
No matching specifications
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
3SU1400-1GC10-1AA0: frequently asked questions
When can 3SU1400-1GC10-1AA0 be shipped?
3SU1400-1GC10-1AA0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3SU1400-1GC10-1AA0 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3SU1400-1GC10-1AA0 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3SU1400-1GC10-1AA0, subject to availability and destination.
