Siemens 3SB3901-1RE
LED lamp, super-bright, yellow, wedge base W2 X 4.6D, rated voltage 28 V AC/DC, operational current 10 mA
- MPN
- 3SB3901-1RE
- Category
- Mounting parts and components
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 3SB3901-1RE?
LED lamp, super-bright, yellow, wedge base W2 X 4.6D, rated voltage 28 V AC/DC, operational current 10 mA
Specifications
General technical data
| product designation | LED lamp, super bright |
| type of light source | LED |
| color of the light source | yellow |
| socket design | W2 x 4.6d |
| product component — series resistor | No |
| product component — diode | No |
| product component — lamp transformer | No |
| product component — light source | Yes |
| type of voltage of the operating voltage for actuation | AC/DC |
| operating voltage — at AC — at 50 Hz rated value | 28 V |
| operating voltage — at AC — at 60 Hz rated value | 28 V |
| operating voltage — at DC rated value | 28 V |
| relative positive tolerance of the operating voltage | 10 % |
| relative negative tolerance of the operating voltage | -15 % |
| consumed current for rated value of supply voltage maximum | 10 mA |
| type of electrical connection | Miscellaneous |
| fastening method | miscellaneous |
Downloads & documentation
Official documents from Siemens, downloaded directly from the manufacturer.
Data sheets & manuals
3SB3901-1RE: frequently asked questions
When can 3SB3901-1RE be shipped?
3SB3901-1RE is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3SB3901-1RE in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3SB3901-1RE and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3SB3901-1RE, subject to availability and destination.
