Siemens 3SB2210-2DE01

Selector switch, 16 mm, round, plastic, green, 3 switch positions I-O-II, latching

MPN: 3SB2210-2DE01
Category: Complete units

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Siemens parts? We buy surplus →

What is the Siemens 3SB2210-2DE01?

Selector switch, 16 mm, round, plastic, green, 3 switch positions I-O-II, latching, Actuating angle 2 x 62 degree, 1 NO, 1 NO

Specifications

General

product brand name	SIRIUS
product designation	Selector switches
design of the product	Complete unit round
product type designation	3SB2

Enclosure

number of command points

Actuator

design of the actuating element	selector switch
principle of operation of the actuating element	latching
product extension optional light source	No
color of the actuating element	green
material of the actuating element	plastic
type of unlocking device	rotate-to-unlatch mechanism
number of switching positions	3
actuating angle — clockwise	62°
actuating angle — anticlockwise	26°

Front ring

product component front ring	Yes
design of the front ring	Standard
material of the front ring	plastic
color of the front ring	black

Holder

material of the holder

Plastic

Contact block/ lampholder

number of lampholders	0
number of switching elements	2

General technical data

product function — positive opening	No
product function — EMERGENCY STOP function	No
type of voltage of the operating voltage	AC/DC
protection class IP	IP65
vibration resistance according to IEC 60068-2-6	20 ... 200 Hz: 5 g
operating frequency maximum	1 000 1/h
mechanical service life (operating cycles) typical	300 000
reference code according to IEC 81346-2	S
Substance Prohibitance (day/month/year)	07/01/2006
Net Weight	0.024 kg
operating voltage rated value	5 ... 250 V

Auxiliary circuit

number of NC contacts for auxiliary contacts	0
number of NO contacts for auxiliary contacts	2
number of CO contacts for auxiliary contacts	0
operational current at AC-12 — at 24 V rated value	10 A
operational current at AC-12 — at 60 V rated value	10 A
operational current at AC-12 — at 110 V rated value	10 A
operational current at AC-12 — at 230 V rated value	10 A
operational current at AC-15 — at 24 V rated value	4 A
operational current at AC-15 — at 110 V rated value	4 A
operational current at AC-15 — at 230 V rated value	4 A
operational current at DC-12 — at 24 V rated value	6 A
operational current at DC-12 — at 60 V rated value	5 A
operational current at DC-12 — at 110 V rated value	2.5 A
operational current at DC-12 — at 230 V rated value	1 A
operational current at DC-13 — at 24 V rated value	3 A
operational current at DC-13 — at 60 V rated value	1.2 A
operational current at DC-13 — at 110 V rated value	0.7 A
operational current at DC-13 — at 230 V rated value	0.3 A

Connections/ Terminals

type of electrical connection	tab terminals
tightening torque of the screws in the bracket maximum	0.4 N·m

Ambient conditions

ambient temperature — during operation	-25 ... +70 °C
ambient temperature — during storage	-40 ... +80 °C
environmental category during operation according to IEC 60721	3K6

Installation/ mounting/ dimensions

fastening method	front plate mounting
shape of the installation opening	round
mounting diameter	16 mm
mounting height	17 mm
installation width	19 mm
installation depth	50 mm

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet 3SB2210-2DE01PDF
