Schneider Electric

Schneider Electric ZBRA3

Wireless and batteryless range, Harmony XB5R, passive antenna to pass through a wall, cable 0.9m, connector SMA female

MPN: ZBRA3
EAN: 3606480991516
Category: Harmony Wireless Push buttons & Ecosystem

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric ZBRA3?

This wireless and batteyless transceiver provides an ergonomic interface for controlling your machines It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65, making it ideal for operation in harsh environments It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly

Specifications

Range of product	Harmony XB5R
Product or component type	Wireless and batteryless range
Device short name	ZBRA
Product destination	For XB5R and XB4R Ø 22 mm control units
Colour of base of enclosure	Black (RAL 9011)
Antenna type	Omnidirectional
Communication port protocol	Zigbee green power at 2.4 GHz conforming to IEEE 802.15.4
Kit composition	Antenna with cable 0.9 m
Input impedance	50 Ohm
Connector type	SMA female
Antenna gain	3 dBi at 83…100 Hz
Maximum sensing distance	10 m transmitters, receivers and relay-antenna
Electrical connection	Cable 2.3 mm² - flexible - 0.9 m
Net weight	0.035 kg
Relative humidity	90 % at -40…70 °C, without condensation conforming to ETSI EN 300 440-1
Electrical shock protection class	Class II conforming to IEC 61140
IP degree of protection	IP65 conforming to IEC 60529
Product certifications	UL, CSA, CE
Standards	IEC 62262, IEC 60947-1

Packaging

Package 1	1 PCE, 11.400 cm × 4.200 cm × 1.400 cm (L × W × H), 30.000 g
Package 2	50 S02, 40.000 cm × 30.000 cm × 15.000 cm (L × W × H), 5.955 kg

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet ZBRA3PDF

ZBRA3: frequently asked questions

When can ZBRA3 be shipped?

ZBRA3 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ZBRA3 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ZBRA3 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ZBRA3, subject to availability and destination.
