Schneider Electric VZ1L018UM20
Line choke - 2 mH - 18 A - 1 phase - 30 W - for variable speed drive
- MPN
- VZ1L018UM20
- EAN
- 3389110890846
- Category
- Altivar 31
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric VZ1L018UM20?
This line choke can be used to provide improved protection against overvoltages on the line supply. It can also be used to reduce harmonic distortion of the current produced by the drive. This product is compliant with IEC 61800-5-1 (VDE 0160 level 1 high-energy overvoltages on the line supply). Its rated current is equal to 18A and its value of inductance to 2mH. It is compatible with Altivar 31, Altivar 32, Altivar 312, Altivar machine ATV320, Lexium 05 and Lexium 32.
Specifications
Specifications
| Range of product | Altivar |
| Product or component type | Line choke |
| Product compatibility | ATV312HU11M2 - line choke - 1 per drive, ATV312HU15M2 - line choke - 1 per drive, ATV312HU22M2 - line choke - 1 per drive, ATV31CU11M2 - line choke - 1 per drive, ATV31CU15M2 - line choke - 1 per drive, ATV31CU22M2 - line choke - 1 per drive, ATV32HU11M2 - line choke - 1 per drive, ATV32HU15M2 - line choke - 1 per drive, ATV32HU22M2 - line choke - 1 per drive, LXM05D17F1 - line choke - 1 per drive, LXM05D17M2 - line choke - 1 per drive, LXM05D28F1 - line choke - 1 per drive, LXM05D28M2 - line choke - 1 per drive, LXM32.D18M2 - line choke - 1 per drive, LXM32.D30M2 - line choke - 1 per drive, LXM32.U90M2 - line choke - 1 per drive, Variable speed drive ATV320 motor: 1.1 kW 200...240 V - single phase - line choke - 1 per drive, Variable speed drive ATV320 motor: 1.5 kW 200...240 V - single phase - line choke - 1 per drive, Variable speed drive ATV320 motor: 2.2 kW 200...240 V - single phase - line choke - 1 per drive |
| number of phases | Single phase |
| Range compatibility | Altivar 312 Solar, Lexium 32, Altivar 312, Altivar 31C, Lexium 05, Altivar Machine ATV320, Altivar 32 |
| Device application | Reduction of current harmonics |
| Value of inductance | 2 mH |
| [In] rated current | 18 A |
| Thermal losses | 30 W |
| power supply frequency | 50...60 Hz |
| Maximum voltage drop at rated load | 5 % |
| Net weight | 1.99 kg |
| Width | 85 mm |
| Height | 120 mm |
| Depth | 105 mm |
| Standards | VDE 0160 level 1, IEC 60076 (with HD398), EN 50178 |
| IP degree of protection | Choke: IP00, Terminals: IP20 |
Packaging
| Package 1 | 1 PCE, 15.000 cm × 15.000 cm × 20.000 cm (L × W × H), 1.928 kg |
| Package 2 | 45 P06, 80.000 cm × 60.000 cm × 75.000 cm (L × W × H), 99.760 kg |
