Schneider Electric TSXPSY8500MC – power supply module - 100..120/200..240 V AC - 500/1700 mA - 75 W
Discontinued by Schneider Electric — we can still source the original TSXPSY8500MC (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon Premium |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| UPC / EAN | 3595863943962 |
| Recommended replacement | BMXCPS4002H |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the TSXPSY8500MC now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXPSY8500MC, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXCPS4002H as its successor — we can quote both.
When can TSXPSY8500MC be shipped?
TSXPSY8500MC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXPSY8500MC in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXPSY8500MC and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXPSY8500MC, subject to availability and destination.
Schneider Electric TSXPSY8500MC — power supply module - 100..120/200..240 V AC - 500/1700 mA - 75 W (Modicon Premium). Discontinued by Schneider Electric; the manufacturer's successor is BMXCPS4002H. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Premium Automation platform |
| Product or component type | Power supply module |
Complementary
| Primary voltage | 100...120 V AC 85...140 V; 200...240 V AC 170...264 V |
| Network frequency | 50/60 Hz |
| Network frequency limits | 47…63 Hz |
| Input current | 1700 mA 100 V; 500 mA 240 V |
| Inrush current | 30 A 100 V; 60 A 240 V |
| I²t on activation | 15 A².s 100 V; 8 A².s 240 V |
| It on activation | 0.15 A.s 100 V; 0.15 A.s 240 V |
| Protection type | Internal fuse 4 A 5 x 20 mm time-delayed primary circuit; Overload protection secondary circuit; Overvoltage protection secondary circuit; Short-circuit protection secondary circuit |
| Total useful secondary power | 100 W at 55 °C with fan module; 77 W at 60 °C; 85 W at 55 °C |
| Secondary power | 75 W 5 V DC |
| Current at secondary voltage | 1.6 A 24 V DC sensor power supply; 15 A 5 V DC |
| Insulation resistance | >= 100 MOhm primary/ground; >= 100 MOhm primary/secondary |
| Marking | CE |
| Local signalling | 1 LED (green) for presence of sensor voltage (24V); 1 LED (green) for presence of voltages (OK); 1 LED (red) for battery fault (BAT) |
| Module format | Double |
| Net weight | 0.74 kg |
Environment
| Immunity to microbreaks | 10 ms |
| Dielectric strength | 2000 V primary/earth; 2000 V primary/secondary |
| Standards | CSA C22.2 No 142; IEC 61131-2; CSA C22.2 No 213 Class I Division 2 Group A; CSA C22.2 No 213 Class I Division 2 Group C; CSA C22.2 No 213 Class I Division 2 Group B; UL 508; 89/336/EEC; 92/31/EEC; 93/68/EEC; CSA C22.2 No 213 Class I Division 2 Group D; 73/23/EEC |
| Product certifications | GL; DNV; RMRS; LR; ABS; BV; RINA |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation; 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | Conformal coating Humiseal 1A33; TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet TSXPSY8500MC |
