Schneider Electric TSXPSY5520MC – power supply module - 24..48 V DC - <= 1500/<= 3000 mA - IP20
Discontinued by Schneider Electric — we can still source the original TSXPSY5520MC (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon Premium |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| UPC / EAN | 3595863950724 |
| Recommended replacement | BMXCPS3020H |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the TSXPSY5520MC now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXPSY5520MC, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXCPS3020H as its successor — we can quote both.
When can TSXPSY5520MC be shipped?
TSXPSY5520MC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXPSY5520MC in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXPSY5520MC and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXPSY5520MC, subject to availability and destination.
Schneider Electric TSXPSY5520MC — power supply module - 24..48 V DC - <= 1500/<= 3000 mA - IP20 (Modicon Premium). Discontinued by Schneider Electric; the manufacturer's successor is BMXCPS3020H. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Premium Automation platform |
| Product or component type | Power supply module |
Complementary
| Primary voltage | 24...48 V DC 19.2...60 V |
| Input current | <= 1500 mA 48 V; <= 3000 mA 24 V |
| Inrush current | 15 A 24 V; 15 A 48 V |
| I²t on activation | 50 A².s 24 V; 55 A².s 48 V |
| It on activation | 6 A.s 48 V; 7 A.s 24 V |
| Protection type | Internal fuse 5 A 5 x 20 mm time-delayed primary circuit; Overload protection secondary circuit; Overvoltage protection secondary circuit; Short-circuit protection secondary circuit |
| Total useful secondary power | 50 W |
| Secondary power | 19 W 24 V DC; 35 W 5 V DC |
| Current at secondary voltage | 0.8 A 24 V DC relay power supply; 7 A 5 V DC |
| Insulation resistance | >= 10 mOhm primary/ground; >= 10 mOhm primary/secondary |
| Marking | CE |
| Local signalling | 1 LED (green) for presence of voltages (OK); 1 LED (red) for battery fault (BAT) |
| Module format | Double |
| Net weight | 0.89 kg |
Environment
| Immunity to microbreaks | 1 ms |
| Dielectric strength | 2000 V primary/earth; 2000 V primary/secondary |
| Standards | 73/23/EEC; 92/31/EEC; CSA C22.2 No 213 Class I Division 2 Group D; 89/336/EEC; CSA C22.2 No 142; IEC 61131-2; 93/68/EEC; UL 508; CSA C22.2 No 213 Class I Division 2 Group B; CSA C22.2 No 213 Class I Division 2 Group C; CSA C22.2 No 213 Class I Division 2 Group A |
| Product certifications | LR; RINA; BV; DNV; RMRS; GL; ABS |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation; 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC; Conformal coating Humiseal 1A33 |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet TSXPSY5520MC |
