Schneider Electric TSXP57354MC

Unity processor - 8 racks (12 slots) / 16 racks (4/6/8 slots) - 1180 mA, 5 V DC

MPN: TSXP57354MC
EAN: 3595863942255
Category: Modicon Premium

Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original TSXP57354MC (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric TSXP57354MC?

Schneider Electric TSXP57354MC — Unity processor - 8 racks (12 slots) / 16 racks (4/6/8 slots) - 1180 mA, 5 V DC (Modicon Premium). Discontinued by Schneider Electric; the manufacturer's successor is BMEP583020. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	Modicon Premium Automation platform
Product or component type	Unity processor
Software designation	Unity Pro

Complementary

Number of racks	16 4/6/8 slots; 8 12 slots
Number of slots	128; 96; 64
Discrete I/O processor capacity	1024 I/O
Analogue I/O processor capacity	128 I/O
Number of application specific channel	32
Number of process control channel	15 up to 45 simple loops
Integrated connection type	Non isolated serial link 2 female mini DIN connector (RS485) (19.2/115 kbit/s); Fipio manager (127 agents) SUB-D 9 connector
Communication module processor capacity	1; 3; 8
Memory description	Internal RAM (with PCMCIA card) 1792 kB program; Internal RAM (with PCMCIA card) 208 kB data; Internal RAM (without PCMCIA card) 208 kB program and data; PCMCIA card 16384 kB additional data storage
Maximum size of object areas	16384 %Mi located internal bits; 64 %KWi constant words located internal data; 64 %MWi internal words located internal data; 64 kB (DFB and EFB function blocks) unlocated internal data; 64 kB (elementary and derived data) unlocated internal data
Application structure	64 event tasks; 1 master task; 1 fast task
Execution time per instruction	0.12 µs Boolean without PCMCIA card; 0.17 µs Boolean with PCMCIA card; 0.17 µs word or fixed-point arithmetic without PCMCIA card; 0.32 µs word or fixed-point arithmetic with PCMCIA card; 1.75...3 µs floating points with PCMCIA card; 1.75...3 µs floating points without PCMCIA card
Number of instructions per ms	3.11 Kinst/ms 65 % Boolean + 35 % fixed arithmetic with PCMCIA card; 4.59 Kinst/ms 100 % Boolean with PCMCIA card; 5.11 Kinst/ms 65 % Boolean + 35 % fixed arithmetic without PCMCIA card; 6.72 Kinst/ms 100 % Boolean without PCMCIA card
System overhead	0.35 ms for fast task; 1 ms for master task
Marking	CE
Local signalling	1 LED (green) for processor running (RUN); 1 LED (red) for activity on Fipio bus (FIP); 1 LED (red) for I/O module or configuration fault (I/O); 1 LED (red) for processor or system fault (ERR); 1 LED (yellow) for activity on TER or AUX terminal port (TER)
Current consumption	1180 mA at 5 V DC
Module format	Double
Net weight	0.56 kg

Environment

Standards	UL 508; CSA C22.2 No 213 Class I Division 2 Group A; CSA C22.2 No 213 Class I Division 2 Group C; 93/68/EEC; 73/23/EEC; IEC 61131-2; 92/31/EEC; 89/336/EEC; CSA C22.2 No 213 Class I Division 2 Group B; CSA C22.2 No 142; CSA C22.2 No 213 Class I Division 2 Group D
Product certifications	BV; DNV; GL; LR; RINA; ABS; RMRS
Ambient air temperature for operation	0…60 °C
Ambient air temperature for storage	-25…70 °C
Relative humidity	10…95 % without condensation for operation; 5…95 % without condensation for storage
Operating altitude	0...2000 m
Protective treatment	TC; Conformal coating Humiseal 1A33
IP degree of protection	IP20
Pollution degree	2

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet TSXP57354MCPDF

TSXP57354MC: frequently asked questions

Can I still buy the TSXP57354MC now that it is discontinued?

Yes. Schneider Electric has discontinued the TSXP57354MC, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMEP583020 as its successor — we can quote both.

When can TSXP57354MC be shipped?

TSXP57354MC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up TSXP57354MC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for TSXP57354MC and we'll include express shipping options in our reply.
