AccuSine+ auxiliary transformer - 1/5 - Step-up Transformer to 5 A
Schneider Electric AccuSine+ auxiliary transformer - 1/5 - Step-up Transformer to 5 A, manufacturer part number PCSPCT190X10005. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
| Range | AccuSine |
| Product or component type | Auxiliary transformer |
| Accessory / separate part category | Measurement accessory |
| Range compatibility | AccuSine AccuSine PCS+ active harmonic filter, AccuSine AccuSine PFV+ electronic VAR controller |
| Secondary current | 5 A |
| Current transformer ratio | 1/5 |
| Electrical connection | Studs: 2500 V |
| Input impedance | 0.5 Ohm |
| [In] rated current | 1 A |
| thermal factor | 1.33 at 30 °C, 1 at 55 °C |
| Network frequency | 50...400 Hz |
| [Ue] rated operational voltage | 600 V AC 50...400 Hz |
| [Uimp] rated impulse withstand voltage | 10 kV (50 µs) |
| Mounting mode | By screws |
| Mounting support | Plate |
| Width | Base width: 114.3 mm, Body: 114.3 mm |
| Height | Body: 124 mm |
| Depth | Base depth : 119.1 mm, Body : 55.6 mm |
| Net weight | 1.8 kg |
| Product certifications | cURus, CSA |
| Package 1 | 1 PCE, 28.6 cm × 22.2 cm × 15.4 cm (L × W × H), 3.0 kg |
No matching specifications
Official documents from Schneider Electric, downloaded directly from the manufacturer.
PCSPCT190X10005 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Yes — mention it when you request a quote for PCSPCT190X10005 and we'll include express shipping options in our reply.
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for PCSPCT190X10005, subject to availability and destination.
