Schneider Electric NSYSMXEB
Set of 4 PanelSeT SM M12 lifting eyebolt - stainless steel
- MPN
- NSYSMXEB
- EAN
- 3606489749101
- Category
- PanelSeT SMX
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYSMXEB?
Set of M12 stainless steel AISI 304 eyebolts for lifting and transporting of PanelSeT SFX, PanelSeT SMX, PanelSeT SF and PanelSeT SM enclosures suites The kit is made of 4 eyebolts, 4 fixing nuts and 4 washers Maximum load is 340kg for 1 eyebolt vertical direction
Specifications
Specifications
| Area | PanelSeT |
| category | Lifting accessory |
| Product or component type | Lifting bracket, Lifting eye |
| Application | Multi-purpose |
| Mounting location | Enclosure top |
| Range compatibility | PanelSeT PanelSeT SFX, PanelSeT PanelSeT SMX, PanelSeT PanelSeT SF, PanelSeT PanelSeT SM |
| Device composition | 4 eyebolt, 4 fixing nuts, 4 washer |
| Material | Stainless steel AISI 304 |
| Fixing mode | Screwed |
| Permanent permissible load | 340 kg for 1 eyebolt vertical direction |
| Height | 73.5 mm |
| Width | 54 mm |
| Depth | 30 mm |
| Diameter | 30 mm |
| ISO thread | M12 |
Packaging
| Package 1 | 1 PCE, 14.200 cm × 9.000 cm × 6.000 cm (L × W × H), 672.000 g |
