Schneider Electric NSYSBM15158
Metal industrial box plain door H150xW150xD80 IP66 IK10 RAL 7035
- MPN
- NSYSBM15158
- EAN
- 3606480520013
- Category
- PanelSeT SBM
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYSBM15158?
Spacial SBM steel industrial box is designed for a multi-purpose application This box is certified by LR, DNV-GL, UL and BV and is wall mounted It has a nominal height, width and depth of 150mm, 150mm and 80mm respectively It is made of sheet steel with a grey color (RAL7035) and a polyester powder surface finish It consists of 4 cover screws, a cover and a body The body is a single piece folded and welded and the cover is fixed with a half turn metal screw The box has a captive screw PZ2 outside the sealed area and the cover can be removed for maintenance purposes The net weight of the enclosure is 1,114kg and it has an IK10 (IEC62262) and IP66 rating (IEC60529) The ambient air temperature for storage and operation is -35-60°C and -35-80°C respectively This device is qualified as a green premium product, with minimal use of harzardous substances.
Specifications
Specifications
| Range | PanelSeT |
| Product name | PanelSeT SBM |
| Device application | Multi-purpose |
| Category | Industrial box |
| Device short name | SBM |
| enclosure type | Flat face box |
| Enclosure nominal height | 150 mm |
| Enclosure nominal width | 150 mm |
| Enclosure nominal depth | 80 mm |
| Enclosure mounting | Wall mounted |
| Device composition | 4 cover screw, 1 cover, 1 body |
| Body type | Single piece body folded and welded |
| Type of front cover | Plain door |
| Cover fixing | Half turn metal screw |
| Lock type | Captive screw PZ2 outside sealed area |
| Removable parts | Cover by captive screws |
| Material | Sheet steel |
| Surface finish | Polyester powder |
| Colour | Grey (RAL 7035) |
| Standards | IEC 62208, UL, CUL |
| Product certifications | DNV-GL, UL, BV |
| IP degree of protection | IP66 conforming to IEC 60529 |
| IK degree of protection | IK10 conforming to IEC 62262 |
| Ambient air temperature for storage | -35…60 °C |
| Operating temperature | -35…80 °C |
| Net weight | 1.114 kg |
Packaging
| Package 1 | 1 PCE, 17.000 cm × 17.000 cm × 10.000 cm (L × W × H), 1.114 kg |
| Package 2 | 114 P12, 120.000 cm × 80.000 cm × 45.000 cm (L × W × H), 137.000 kg |
