Schneider Electric NSYS06

Safety terminals section 1x6mm² . Supply : 20

MPN: NSYS06
Category: PanelSeT CRN

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Schneider Electric NSYS06?

Schneider Electric Safety terminals section 1x6mm² . Supply : 20, manufacturer part number NSYS06. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Accessory / separate part category	Power distribution
Product or component type	Safety terminal
Device application	Multi-purpose
Range compatibility	PanelSeT, Thalassa
Device composition	1 sigma terminal
Quantity per set	Set of 20
Nominal cross section	6 mm² 1
Mounting location	On mounting accessories
Material	Polyamide 6 matt black for base, Polypropylene orange for cover, MS-58 brass for terminal, Zinc-plated and dichromated steel for ring
Height	25 mm
Width	16 mm
Depth	33 mm
Diameter	16 mm
Coverage	Core product

Packaging

Package 1	1 PCE, 13.000 cm × 9.500 cm × 0.650 cm (L × W × H), 8.000 g
Package 2	20 BB1, 13.000 cm × 9.500 cm × 2.500 cm (L × W × H), 164.000 g
Package 3	1560 CAR, 60.000 cm × 40.000 cm × 30.000 cm (L × W × H), 13.492 kg
