Schneider Electric NSYPCVDN208
Ventilated single door;PanelSeT SFN; for 19" electronic enclosure H2000 W800mm
- MPN
- NSYPCVDN208
- EAN
- 3606487084877
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYPCVDN208?
This is a ventilated door for 19" rack designed to achieve natural airing of the enclosure. It is purpose-built to assemble a PanelSeT SFN electrical enclosure with dimensions of 2000mm height and 800mm width for Electronic applications. The nominal height and width are 2000 mm and 800 mm, respectively. It is made of steel sheets, while the handle is made of polyamide 6 with 30% fiberglass. An epoxy-polyester powder finish provides a smooth appearance. It has a grey (RAL 7035) color. The kit contains the door and handle. This product is qualified as a green premium, with minimal use of hazardous substances.
Specifications
Specifications
| Range | PanelSeT |
| Accessory / separate part category | Enclosure accessory |
| Product or component type | 19" door |
| Application | Electronic application, Multi-purpose |
| For enclosure nominal dimensions | - |
| Mounting location | Front |
| Range compatibility | PanelSeT SFN |
| Device composition | 1 door, 1 lock with handle and 5 mm double bar insert, 1 locking bar system 4 points |
| Quantity per set | Set of 1 |
| Material | Sheet steel |
| Colour | Grey (RAL 7035) |
| Surface finish | Epoxy-polyester powder |
| Lock type | Lock 5 mm double bar |
| Number of locks | 1 |
| Door type | Ventilated |
| Door opening side | Reversible (120 °) |
| Height | Nominal: 2000 mm |
| Width | Nominal: 800 mm |
Packaging
| Package 1 | 1 PCE, 5.500 cm × 79.000 cm × 200.000 cm (L × W × H), 31.000 kg |
| Package 2 | 10 P2M, 120.000 cm × 200.000 cm × 73.000 cm (L × W × H), 332.000 kg |
