Plain mounting plate H300xW800mm made of galvanised sheet steel

Name: Schneider Electric NSYMM38SB – Plain mounting plate H300xW800mm made of galvanised sheet steel
Brand: Schneider Electric
SKU: NSYMM38SB

MPN: NSYMM38SB · Brand: Schneider Electric

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	PanelSeT SBM
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	3.35 kg

Shipping & availability

When can NSYMM38SB be shipped?

NSYMM38SB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up NSYMM38SB in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for NSYMM38SB and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYMM38SB, subject to availability and destination.

Schneider Electric Plain mounting plate H300xW800mm made of galvanised sheet steel, manufacturer part number NSYMM38SB. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Range	PanelSeT
Accessory / separate part category	Mounting accessory
Product or component type	Mounting plate
Device application	Multi-purpose
Enclosure nominal dimensions	-
Mounting location	Bottom of enclosure
Mounting plate description	Plain
Range compatibility	PanelSeT SBM
Device composition	1 mounting plate
Material	Galvanised steel
Surface finish	Metallic
Fixing mode	By 2 screws - screw type Ø5 mm self-tapping screws - bottom of enclosure location
Permanent permissible load	12 kg back of the enclosure
Height	Nominal: 275 mm
Width	Nominal: 785 mm, Fixing centers: 764 mm
Surface and useful surface	Nominal: 240000 mm²
thickness	2 mm
Net weight	3.352 kg
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	79.000 cm
Package 1 Width	28.000 cm
Package 1 Length	0.300 cm
Package 1 Weight	3.460 kg
Unit Type of Package 2	P12
Number of Units in Package 2	60
Package 2 Height	45.000 cm
Package 2 Width	80.000 cm
Package 2 Length	120.000 cm
Package 2 Weight	220.000 kg
Warranty (in months)	18
