Schneider Electric NSYFPLS2754G
Polyester rear part of PLS box 27x54x13.5cm
- MPN
- NSYFPLS2754G
- EAN
- 3606480774003
- Category
- PanelSeT PLS
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric NSYFPLS2754G?
Schneider Electric Polyester rear part of PLS box 27x54x13.5cm, manufacturer part number NSYFPLS2754G. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Range | PanelSeT |
| Product name | PanelSeT PLS |
| Device short name | PLS |
| Enclosure type | Multi-purpose |
| Category | Insulating modular rear |
| Nominal height | 270 mm |
| Nominal width | 540 mm |
| Nominal depth | 135 mm |
| Enclosure mounting | Wall mounted |
| Device composition | 1 rear part: on enclosure |
| Body type | One piece moulded |
| Type of front cover | Without |
| Material | Polyester reinforced with fibreglass |
| Colour | Body: grey (RAL 7035) |
| Standards | IEC 62208, NEMA classification 13, NEMA 4X |
| Product certifications | UL |
| Electrical insulation class | Class II |
| IP degree of protection | IP66 conforming to IEC 60529 |
| IK degree of protection | IK09 conforming to IEC 62262 |
| Fire resistance | 960 °C conforming to IEC 62208 |
| Ambient air temperature for storage | -30…70 °C |
Packaging
| Package 1 | 1 PCE, 14.000 cm × 27.000 cm × 54.000 cm (L × W × H), 1.954 kg |
| Package 2 | 42 PAM, 120.000 cm × 100.000 cm × 126.000 cm (L × W × H), 97.300 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
NSYFPLS2754G: frequently asked questions
When can NSYFPLS2754G be shipped?
NSYFPLS2754G is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYFPLS2754G in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYFPLS2754G and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYFPLS2754G, subject to availability and destination.
