Half flush mounting kit for Side Connected Cooling Unit, Climasys CU, 3,2 - 4kW
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | ClimaSys CU |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 14 kg |
Shipping & availability
When can NSYCUACC037DG be shipped?
NSYCUACC037DG is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYCUACC037DG in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYCUACC037DG and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYCUACC037DG, subject to availability and destination.
Schneider Electric Half flush mounting kit for Side Connected Cooling Unit, Climasys CU, 3,2 - 4kW, manufacturer part number NSYCUACC037DG. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Range of product | ClimaSys |
| Product name | CU |
| Product or component type | Mounting adaptor |
| Product destination | Mounting adaptor for side cooling unit 3200 W, Side cooling unit 4000 W |
| Offer type | Complementary |
| Mounting location | Door of enclosure, Side of enclosure |
| fixing mode | By bolt |
| Device composition | 1 mounting adaptor: inside the enclosure, 1 gasket: inside the enclosure, 12 bolt: outside |
| Material | Galvanized steel |
| Colour | Grey (RAL 7035) |
| Height | 1373 mm |
| Width | 560 mm |
| Depth | 124 mm |
| Quantity per set | 1 |
| IP degree of protection | IP55 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 14.500 cm |
| Package 1 Width | 59.000 cm |
| Package 1 Length | 139.000 cm |
| Package 1 Weight | 14.000 kg |
| Unit Type of Package 2 | P2M |
| Number of Units in Package 2 | 8 |
| Package 2 Height | 76.000 cm |
| Package 2 Width | 120.000 cm |
| Package 2 Length | 200.000 cm |
| Package 2 Weight | 144.000 kg |
| Warranty (in months) | 18 |
