ClimaSys CV - CSVS FanSensor
MPN: NSYCCARPM · Brand: Schneider Electric
Price on request
Request a Quote
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Category | ClimaSys CC |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 130 kg |
Shipping & availability
When can NSYCCARPM be shipped?
NSYCCARPM is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up NSYCCARPM in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for NSYCCARPM and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NSYCCARPM, subject to availability and destination.
Specifications
Specifications
| Range | ClimaSys |
| Product name | ClimaSys CC |
| Product or component type | RPM and temperature sensor |
| Product compatibility | ClimaSys DG 230/400 V AC fan 115 V, ClimaSys CV 230/400 V AC standard fan 115 V, ClimaSys CV grille adapted to integrate dust sensor |
| Sensor type | RPM reader by infrared light sensor, Small toroidal for current consumption |
| Type of measurement | Fan speed range measurement range: 80...5800 rpm, Fan current range measurement range: 40...1500 mA: through toroidal clamp (no need to disconnect the fan for sensor installation), Fan current range measurement range: 40...1500 mA: snap on-off system, RPM: transported air across roof blades or lateral fans, Temperature: transported air across roof blades or lateral fans |
| Mounting location | Behind fan |
| Mounting mode | By clips |
| Communication interface | Modbus between sensor and controller |
| Connections - terminals | Mini connector Modbus (4 wires) |
| Local signalling | Fault indication: 1 red LED by blinking, Bad position: 1 red LED by blinking, Sensor position: 1 green LED by flashing |
| Material | Injected thermoplastic (PC) |
| Quantity per set | Set of 1 |
| Height | 61.9 mm |
| Width | 48.6 mm |
| Depth | 15.2 mm |
| Colour | Transparent green (Pantone 355C) |
| Product certifications | CE, EAC, EMC directive 89/336 EEC |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 3.000 cm |
| Package 1 Width | 10.500 cm |
| Package 1 Length | 15.000 cm |
| Package 1 Weight | 130.000 g |
| Unit Type of Package 2 | CAR |
| Number of Units in Package 2 | 55 |
| Package 2 Height | 24.500 cm |
| Package 2 Width | 34.000 cm |
| Package 2 Length | 42.500 cm |
| Package 2 Weight | 7.670 kg |
| Coverage | Core product |
| Warranty | 18 months |
