Schneider Electric LV432491
Terminal extensions, ComPacT NSX 400/630, spreaders 45mm to 52.5mm pitch, set of 4 parts
- MPN
- LV432491
- EAN
- 3606480019661
- Category
- ComPacT NSX, new generation
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric LV432491?
These accessories are spreaders for 3 poles Compact NSX 400/630 and EasyPact CVS 400/630. They are screwed to the circuit-breaker terminals to increase the pitch between poles from 45mm to 52.5mm. The rated current is up to 630 A. These spreaders are supplied with flexible interphase barriers for insulation reinforcement. They are sold by set of 4 parts.
Specifications
Specifications
| Product or component type | Spreader |
| Accessory / separate part category | Connection accessory |
| Range compatibility | ComPacT ComPacT NSX400, ComPacT ComPacT NSX630, ComPacT ComPacT NSX DC, ComPact ComPact NSX400, ComPact ComPact NSX630, ComPact Compact NSX400 DC, ComPact Compact NSX630 DC, EasyPact EasyPact CVS400, EasyPact EasyPact CVS630, ComPact ComPacT INS, ComPact Compact INV |
| Poles description | 4P |
| Quantity per set | 4 |
| Mounting position | Straight |
| [In] rated current | 630 A |
| Connection pitch | 52.5 mm |
Packaging
| Package 1 | 1 PCE, 22.000 cm × 20.000 cm × 5.000 cm (L × W × H), 1.257 kg |
| Package 2 | 12 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 15.482 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
LV432491: frequently asked questions
When can LV432491 be shipped?
LV432491 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up LV432491 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for LV432491 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LV432491, subject to availability and destination.
