Schneider Electric LV429236
Long rear connections, ComPacT NSX, EasyPact CVS, 250A, set of 2 parts
- MPN
- LV429236
- EAN
- 3606480019708
- Category
- ComPacT NSX, new generation
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric LV429236?
These accessories are short rear connections for Compact NSX 100/160/250 and EasyPact CVS 100/160/250. The rear connection is simply fitted to the device connection terminals. Device mounting on a backplate with suitable holes enables rear connection. The length is approximately 88mm. The rated current is up to 250 A. They are sold by set of 2 parts.
Specifications
Specifications
| Range of product | ComPacT NSX100...250, ComPacT NSX100...250 DC |
| Product or component type | Long rear connection |
| Accessory / separate part category | Connection accessory |
| Range compatibility | ComPacT ComPacT NSX100, ComPacT ComPacT NSX160, ComPacT ComPacT NSX250, ComPacT Compact NSX100 DC, ComPacT Compact NSX160 DC, ComPacT Compact NSX250 DC, ComPacT EasyPact CVS100, ComPacT EasyPact CVS160, ComPacT EasyPact CVS250, ComPacT ComPacT INS, ComPacT Compact INV |
| Poles description | 4P, 3P |
| [In] rated current | 250 A |
| Location of connection | Rear |
| Localisation on device | Top and bottom |
| Shape | Long |
| Quantity per set | Set of 2 |
Packaging
| Package 1 | 1 PCE, 13.200 cm × 11.200 cm × 3.400 cm (L × W × H), 275.200 g |
| Package 2 | 12 BB1, 35.000 cm × 20.000 cm × 10.500 cm (L × W × H), 3.522 kg |
| Package 3 | 60 S04, 60.000 cm × 40.000 cm × 30.000 cm (L × W × H), 17.272 kg |
