Low level auxiliary contact, circuit breaker status OF/SD/SDE/SDV, 1 changeover contact type
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | ComPacT NSX, new generation |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 0.02 kg |
Shipping & availability
When can 29452 be shipped?
29452 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 29452 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 29452 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 29452, subject to availability and destination.
It is a single low-level auxiliary contact that provides all the different indications remotely for Compact NSX, Compact NS, PowerPact Multistandard and EasyPact CVS circuit breakers. Remote status information are ON/OFF (OF), trip indication (SD) and fault-trip indication (SDE) for all circuit breakers types. The remote status information for trip indication due to an earth fault (SDV) is used for Compact NSX and PowerPact Multistandard. The contacts are installed in the device in dedicated slots. This auxiliary contact is a common point changeover type contact with 1 normally open contact and 1 normally closed contact. The rated current is 5A and the minimum load is 1MA at 4 VDC for utilization categories AC12/AC15/DC12/DC14. One device embeds 5 auxiliaries contact type. It complies with IEC 60947-5-1 standard.
Specifications
Specifications
| Product or component type | Auxiliary contact |
| Device short name | SD, SDV, OF, SDE |
| Device application | Breaker status monitoring |
| Range compatibility | Galaxy PX, Galaxy VL, Galaxy VM, Galaxy VS, Galaxy VX |
| Signal contacts composition | 1 NO/NC |
| Fault type | General electric fault |
| Local signalling | ON/OFF indication for open/close, Trip indicator for relay trip indicator, Fault trip for electrical fault |
| Auxiliary contacts type | Low level |
| Mounting mode | Clip-on |
| [Ith] conventional free air thermal current | 5 A |
| Breaking capacity (A) | AC-12: 5 A at 24 V AC 50/60 Hz, AC-12: 5 A at 48 V AC 50/60 Hz, AC-12: 5 A at 110 V AC 50/60 Hz, AC-12: 5 A at 220/240 V AC 50/60 Hz, AC-12: 5 A at 380/440 V AC 50/60 Hz, AC-12: 5 A at 480 V AC 50/60 Hz, AC-15: 3 A at 24 V AC 50/60 Hz, AC-15: 3 A at 48 V AC 50/60 Hz, AC-15: 2.5 A at 110 V AC 50/60 Hz, AC-15: 2 A at 220/240 V AC 50/60 Hz, AC-15: 1.5 A at 380/440 V AC 50/60 Hz, AC-15: 1 A at 480 V AC 50/60 Hz, DC-12: 5 A at 24 V DC, DC-12: 2.5 A at 48 V DC, DC-12: 0.6 A at 110 V DC, DC-12: 0.3 A at 250 V DC, DC-14: 1 A at 24 V DC, DC-14: 0.2 A at 48 V DC, DC-14: 0.05 A at 110 V DC, DC-14: 0.03 A at 250 V DC |
| Minimum load | 1 mA at 4 V DC |
| Accessory / separate part category | Spare part for Compact NS630b...1600, Spare part for Compact NS1600b...3200 |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 1.400 cm |
| Package 1 Width | 7.800 cm |
| Package 1 Length | 6.000 cm |
| Package 1 Weight | 22.000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 10 |
| Package 2 Height | 5.000 cm |
| Package 2 Width | 14.500 cm |
| Package 2 Length | 17.000 cm |
| Package 2 Weight | 228.000 g |
| Unit Type of Package 3 | S02 |
| Number of Units in Package 3 | 100 |
| Package 3 Height | 15.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 2.500 kg |
| Warranty (in months) | 18 |
