Acti9 - IHH - mechanical time switch - 7 days - 150 h memory

Name: Acti9 - IHH - mechanical time switch - 7 days - 150 h memory
Brand: Schneider Electric
SKU: 15331

MPN: 15331 · Brand: Schneider Electric

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	IH
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.1 kg

Shipping & availability

When can 15331 be shipped?

15331 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 15331 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 15331 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 15331, subject to availability and destination.

Specifications

range of product	Acti9
Product name	Acti9 IHH
Device short name	IHH
Product or component type	Mechanical time switch
Number of channels	1
Function available	Manual time changeover
Device application	Building
Load type	Parallel-corrected fluorescent tube 5 x 58 W 4.7 µF, Parallel-corrected fluorescent tube 7 x 40 W 7 µF, Parallel-corrected fluorescent tube 2 x 100 W 18 µF, 230 V AC halogen lamp 1000 W, 230 V AC incandescent lamp 1000 W, Fluocompact lamp 700 VA, Compact fluorescent lamp 150 W, LED lamp < 2 W 30 W, LED lamp > 2 W 300 W
Cycle duration	7 days
Maximum number of switchings	42 on - 42 off
Minimum interval duration	2 h
Type of setting	Manual time changeover
Measurement accuracy	+/- 1 s/day 20 °C
Power consumption in W	0.5 W
Maximum switching current	16 A - 250 V AC pf = 1, 4 A - 250 V AC pf = 0.6
[Ue] rated operational voltage	230...240 V AC at 50...60 Hz
Battery life	10 year(s)
Backup time	150 h time and program saving
Mounting support	DIN rail
9 mm pitches	2
Colour tint	White (RAL 9003)
Connections - terminals	Screw terminals
Width	18 mm
Height	90 mm
Depth	66 mm
Net weight	0.101 kg
Ambient air temperature for operation	-10…50 °C
IP degree of protection	Terminals: IP20 B
Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	2 cm
Package 1 Width	7 cm
Package 1 Length	10 cm
Package 1 Weight	89 g
Unit Type of Package 2	S03
Number of Units in Package 2	100
Package 2 Height	30 cm
Package 2 Width	30 cm
Package 2 Length	40 cm
Package 2 Weight	9.452 kg
Warranty (in months)	18
