Mitsubishi Electric UA-DL2

Mitsubishi Low-voltage switchgear Related Equipment

MPN
UA-DL2
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric UA-DL2?

The Mitsubishi Electric UA-DL2 is a related Equipment in the Low-voltage switchgear. Instantaneous Stop/Restart Relays. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineInstantaneous Stop/Restart Relays

Specifications

Product SpecificationPlug-in Structure
Operating Voltage: AC100/200V: Connection Terminal Number-2100 to 110VAC 50/60Hz
Operating Voltage: AC100/200V: Connection Terminal Number-7200 to 220VAC 50/60Hz
Operating Voltage: AC120V: Connection Terminal Number-2100 to 110VAC 50/60Hz
Operating Voltage: AC120V: Connection Terminal Number-7110 to 120VAC 50/60Hz
Operating Voltage: AC240V: Connection Terminal Number-2200 to 220VAC 50/60Hz
Operating Voltage: AC240V: Connection Terminal Number-7220 to 240VAC 50/60Hz
Operating Time1 Second/2 Seconds Switchable
Time Accuracy: Setting Error (AC100V/AC200V Applied)-20% to +90%
Time Accuracy: Voltage Error±35%
Time Accuracy: Temperature Error±25%
Minimum Retention Time5s or More
Minimum Off Time50ms
Power Consumption (Rated Voltage Applied)3VA
Output Contact: Contact Arrangement1NA
Output Contact: Rated Operating Current [A] Category AC-15: AC110V1.5
Output Contact: Rated Operating Current [A] Category AC-15: AC220V1
Applicable Magnetic Contactor Model NamesS-T10 toT100、S-N125 toN400
Function: Operation DisplayLights up when the power is on, turns off when the power is off
Function: Terminal Covers: Socket TerminalNo
Function: Wiring Streamlining Terminal: Socket TerminalNo
Mounting Method: Socket (PF-08RM)Screw and DIN Rail Mounting
Mounting Method: Socket (PF-08TM)Screw Mounting
Terminal Screw Size: Socket TerminalM3.5

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

UA-DL2: frequently asked questions

When can UA-DL2 be shipped?

UA-DL2 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up UA-DL2 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for UA-DL2 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for UA-DL2, subject to availability and destination.
