What is the Mitsubishi Electric TH-N12?

The Mitsubishi Electric TH-N12 is a thermal Overload Relay in the Low-voltage switchgear. Overload Protection Adjustment Range of Setting Current:0.1 to 13A 3-Pole 2-Element For Magnetic Starters. Mitsubishi Electric has discontinued it (2015/10 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
Sales status2015/10 Discontinued (Mitsubishi Electric)
OutlineOverload Protection Adjustment Range of Setting Current:0.1 to 13A 3-Pole 2-Element For Magnetic Starters

Specifications

Product SpecificationStandard Type
Rated Insulation Voltage Ui [V]690
Elements2
Protection ModeOverload Protection
Adjustment Range of Setting Current [A]0.1 to 13
Tripping Class10A
Heater Designation [A]: Category-10.12 to 9
Heater Designation [A]: Category-211
Combined Magnetic Contactor Frame: Category-1N10,N11,N12
Combined Magnetic Contactor Frame: Category-2N11,N12
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC24V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC120V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC240V1
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC550V0.5
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC24V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC120V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC240V1
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC550V0.5
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC24V0.5
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC110V0.2
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC220V0.1
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC24V0.5
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC110V0.2
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC220V0.1
Conventional Free Air Thermal Current [A]2
Minimal Applicable Load20V 5mA
Contact Arrangements (Valid)1NO1NC
Function: Terminal CoversNo
Function: Wiring Streamlining TerminalNo
Independent MountingNot Available(Enabled by Combining with UN-HZ12)
Terminal Screw Size: Main Circuit (Load Side)M3.5
Terminal Screw Size: Operating CircuitM3.5
