SW3DND-SHEETSET-E Mitsubishi MELSEC-Q Series MELSOFT MX Works
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Mitsubishi MELSEC-Q Series – Software |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can SW3DND-SHEETSET-E be shipped?
SW3DND-SHEETSET-E is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up SW3DND-SHEETSET-E in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for SW3DND-SHEETSET-E and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SW3DND-SHEETSET-E, subject to availability and destination.
The Mitsubishi Electric SW3DND-SHEETSET-E is a MELSOFT MX Works in the MELSEC-Q Series. Excel® communication support tool MELSOFT MX Works Version3 MELSOFT MX Component Version5 and MX Sheet Version3 Standard license (English) Package edition (DVD). Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | MELSEC-Q Series |
| Category | MELSOFT MX Works |
| Type | English |
| Subtype | Standard license |
| Outline | Excel® communication support tool MELSOFT MX Works Version3 MELSOFT MX Component Version5 and MX Sheet Version3 Standard license (English) Package edition (DVD) |
Specifications
| Category | Software |
| Series name | MELSOFT |
| Product name | MX Works Version3 English |
| Model | SW3DND-SHEETSET-E |
| Product category | MX Works Version3 |
| Shipping type | Package |
| Supported model | PLC: MX Controller, RCPU, RCCPU, R Motion CPU, MELSECWinCPU, FX5CPU, QCPU(Q mode), LCPU, LHCPU, QCCPU, QSCPU,Ｑ Motion CPU, FXCPU Simulator: GX Simulator3, GX Simulator2, MT Simulator2 Invertor: A800 Robot(Controller): CR750-D/CRnD-700 series |
| Configuration of the software package | MX Component Version 5 MX Sheet Version 3 |
| Operating environment: Personal computer | A personal computer on which Microsoft® Windows® operates |
| Operating environment: OS | Windows 11 (Home, Pro, Pro for Workstations, Enterprise, Education, IoT Enterprise 2024), Windows Server 2025 (Standard，Datacenter), Windows Server 2022 (Standard，Datacenter), Windows Server 2019 (Essentials, Standard，Datacenter) |
| Operating environment: CPU | 2 or more cores on a compatible 64-bit processor or System on a Chip (SoC) |
| Operating environment: Required memory | 4 GB or more recommended |
| Operating environment: Available hard disk capacity | For installation: 2.5 GB or more free hard disk capacity For operation: 512 MB or more free virtual memory capacity |
| Operating environment: Disk drive | DVD-ROM Drive |
| Operating environment: Monitor | Resolution WXGA (1280 × 720 pixels) or higher |
| Operating environment: Communication interface | Ethernet, RS-232/422, USB, MELSECNET/H board, CC-Link Ver.2 board, CC-Link IE Controller Network board, CC-Link IE Field Network board, CC-Link IE TSN board |
| Operating environment: Required software | Microsoft Excel 2021/2024, Microsoft Excel for Microsoft 365(64-bit) |
| Language | English |
