SW1DND-GTWK3-EC Mitsubishi GOT HMI Software

MPN: SW1DND-GTWK3-EC · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi GOT HMI – Software
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can SW1DND-GTWK3-EC be shipped?

SW1DND-GTWK3-EC is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SW1DND-GTWK3-EC in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SW1DND-GTWK3-EC and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SW1DND-GTWK3-EC, subject to availability and destination.

The Mitsubishi Electric SW1DND-GTWK3-EC is a software in the GOT HMI. 1. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	GOT HMI
Outline	1

Specifications

Model	SW1DND-GTWK3-EC
Category	Software
Product name	GT Works3 Version1
Series name	MELSOFT GT Series
License type	Site license
Number of licenses	1
Configuration of the software package	GT Designer3 (GOT3000) GT Designer3 (GOT2000) GT SoftGOT3000 Data Transfer Tool GT Reporting Tool GT OPC UA Client Setting Tool Addon Project (GT Designer3 (GOT3000)) etc.
Operating environment: Personal computer	Personal computer that Windows ® runs on.
Operating environment: OS 1 4 7 8 10 11 *12	Microsoft ® Windows ® 11 Education (64 bit) 15 Microsoft ® Windows ® 11 Enterprise (64 bit) 15 Microsoft ® Windows ® 11 Pro (64 bit) 15 Microsoft ® Windows ® 11 Home (64 bit) 15
Operating environment: CPU	Intel Core i3 (8th generation) or later
Operating environment: Required memory	8 GB or more recommended
Operating environment: Available hard disk capacity	For installation: 5 GB or more recommended For execution: 512 MB or more recommended
Operating environment: Display color	High Color (16 bits) or higher
Operating environment: Monitor	9-inch or larger display with FWXGA (1366 x 768 dots) or higher resolution
Operating environment: Communication interface	USB interface, Ethernet interface *9
Operating environment: Other hardware	Use the hardware compatible with the above OS. ・ For installation: mouse, keyboard, DVD drive ・ For execution: mouse, keyboard ・ For printing: printer Use the following hardware when required. ・ For simulation (only when outputting the buzzer sound): sound card, speaker
Language	English Version
Supported model	GOT3000, GOT2000, GT SoftGOT3000
Remarks: License type -1	Anyone can use the product as long as that person belongs to the business office (including overseas offices) of the corporation that purchased the product, or to the same public vocational training facility or other educational institution as the corporation.

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

GT Designer3 (GOT2000) Screen Design Manual (SH-081220ENG-BC)	PDF · 79.03MB
GT Works3 Installation Instructions DVD Version (BCN-P5999-1793-B)	PDF · 0.16MB
GT Designer3 (GOT3000) Screen Design Manual (SH-082590ENG-D)	PDF · 69.82MB
GT SoftGOT2000 Version1 Operating Manual (SH-081201ENG-BA)	PDF · 19.65MB
GT Converter2 Version3 Operating Manual for GT Works3 (SH-080862ENG-Q)	PDF · 0.95MB
GT Converter2 Version3 操作手册对应GT Works3 (SH-081117CHN-M)	PDF · 1.22MB
GOT2000 Series MES Interface Function Manual For GT Works3 Version1 (SH-081228ENG-U)	PDF · 5.18MB
GOT2000系列 MES 接口功能手册对应GT Works3 Version1 (SH-081229CHN-U)	PDF · 5.29MB
Help For Data Transfer Tool (BCN-P5670-AT)	PDF · 1.53MB
Help For Data Transfer Tool Classic (BCN-P5999-1657-A)	PDF · 0.73MB
