What is the Mitsubishi Electric SRL-T5?

The Mitsubishi Electric SRL-T5 is a contactor Relay in the Low-voltage switchgear. 5-Pole Mechanically Latched Type Terminal Covers. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
Outline5-Pole Mechanically Latched Type Terminal Covers

Specifications

Product SpecificationMechanically Latched Type
Rated Insulation Voltage Ui [V]690
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V6
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V3
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V1.5
Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V1.2
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V10
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V8
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V5
Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC24V3
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC48V1.5
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC110V0.6
Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC220V0.3
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC24V3
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC48V1.5
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC110V2
Rated Operating Current [A]: DC Coil Load (Category DC-13) 2-Pole: DC220V0.8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC24V10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC48V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC110V5
Rated Operating Current [A]: DC Resistive Load (Category DC-12) Single-Pole: DC220V1
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC24V10
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC48V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC110V8
Rated Operating Current [A]: DC Resistive Load (Category DC-12) 2-Pole: DC220V3
Conventional Free Air Thermal Current [A]10
Minimal Applicable Load20V 3mA
Contact Arrangements (Valid)5NO,4NO1NC,3NO2NC
Making Current Capacity [A]: Category AC-15: AC120V66
Making Current Capacity [A]: Category AC-15: AC240V55
Making Current Capacity [A]: Category AC-15: AC550V33
Breaking Current Capacity [A]: Category AC-15: AC120V66
Breaking Current Capacity [A]: Category AC-15: AC240V55
Breaking Current Capacity [A]: Category AC-15: AC550V33
Mechanical Durability [Mil.Times]50
Electrical Durability [Mil.Times]: Category AC-1550
Electrical Durability [Mil.Times]: Category DC-1350
Switching Frequency [Times/Hour]1200
Operation Coil Properties: Operating VoltageAC Operated
Operation Coil Properties: Inrush Input [VA]Close:80(AC Operated),Trip:110(AC Operated)
Functions: Coil Surge Absorbing FunctionNo
Functions: Terminal CoversYes
Functions: Wiring Streamlining TerminalNo
Mounting MethodScrew Mounting,DIN Rail Mounting
Terminal Screw Size: Control CircuitM3.5
Terminal Screw Size: Operation CoilM3.5
