SRE-KT Mitsubishi Low-voltage switchgear Related Equipment

MPN: SRE-KT · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Related Equipment
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can SRE-KT be shipped?

SRE-KT is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SRE-KT in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SRE-KT and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SRE-KT, subject to availability and destination.

The Mitsubishi Electric SRE-KT is a related Equipment in the Low-voltage switchgear. For Power Detection. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Outline	For Power Detection

Specifications

Product Specification	Internal relay ON at Detection Voltage
Detection Type	For Standard Detection
Detection Operation	Set Value (Scale) is ON Voltage
Detection Voltage Setting Range [V]	DC:10 to 115V AC:80 to 260V
Detector Input Max. Voltage (Continuous) [V]	DC:14 to 120V AC:120 to 264V
Response Time (150% of Set Voltage Applied)	100ms
Operating Voltage [V]: AC Operated Type for 50/60Hz	AC100V AC120V AC200V AC240V
Operating Voltage [V]: DC Operated Type	DC12V DC24V DC100V
Power Consumption (Rated Operational Voltage Applied)	DC:1.7W AC:1.8VA
Output Contact: Contact Arrangement	1c
Output Contact: Rated Operating Current [A] Category AC-15: AC110V	1.5
Output Contact: Rated Operating Current [A] Category AC-15: AC220V	1
Output Contact: Rated Operating Current [A] Category DC-13: DC110V	0.2
Output Contact: Rated Continuity Current [A]	3
Electrical Durability [Mil.Times]: Category AC-15	50
Electrical Durability [Mil.Times]: Category DC-13	25
Functions: Terminal Covers	No
Functions: Wiring Streamlining Terminal	No
Mounting Method	Screw Mounting
Terminal Screw Size: Control Circuit	M3.5
