SH-V160 Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN: SH-V160 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original SH-V160 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Magnetic Contactors
Lifecycle	Discontinued
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

Can I still buy the SH-V160 now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the SH-V160, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can SH-V160 be shipped?

SH-V160 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SH-V160 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SH-V160 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SH-V160, subject to availability and destination.

The Mitsubishi Electric SH-V160 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 180A(Category AC3 AC200V) AC Operated Vacuum Type. Mitsubishi Electric has discontinued it (2026/07 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Sales status	2026/07 Discontinued (Mitsubishi Electric)
Outline	Representative rating 180A(Category AC3 AC200V) AC Operated Vacuum Type

Specifications

Product Specification	AC Operated Vacuum Magnetic Contactor
Rated Insulation Voltage Ui [V]	1500
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V	45
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V	90
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V	110
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1000V	220
Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1500V	315
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V	180
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V	180
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V	180
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1000V	160
Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC1500V	160
Main Contact Conventional Free Air Thermal Current [A]	200
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V	5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V	3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V	0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V	0.2
Auxiliary Contact Minimal Applicable Load	48V 200mA
Contact Arrangements (Valid): Main Contact (Standard)	3NO
Contact Arrangements (Valid): Auxiliary Contact (Standard)	2NO2NC
Contact Arrangements (Valid): Auxiliary Contact (Special)	4NO4NC
Main Contact Making Current Capacity [A]: Category AC-3: AC220V	1800
Main Contact Making Current Capacity [A]: Category AC-3: AC440V	1800
Main Contact Making Current Capacity [A]: Category AC-3: AC550V	1800
Main Contact Making Current Capacity [A]: Category AC-3: AC1000V	1600
Main Contact Making Current Capacity [A]: Category AC-3: AC1500V	1600
Main Contact Breaking Current Capacity [A]: Category AC-3: AC220V	1440
Main Contact Breaking Current Capacity [A]: Category AC-3: AC440V	1440
Main Contact Breaking Current Capacity [A]: Category AC-3: AC550V	1440
Main Contact Breaking Current Capacity [A]: Category AC-3: AC1000V	1280
Main Contact Breaking Current Capacity [A]: Category AC-3: AC1500V	1280
Mechanical Durability [Mil.Times]	250
Electrical Durability [Mil.Times]: Category AC-3 (Japan)	50
Switching Frequency [Times/Hour]: Category AC-3	1200
Operation Coil Properties: Operating Voltage	AC Operated
Operation Coil Properties: Inrush Input [VA]	480
Operation Coil Properties: Normal input [VA]	44
Functions: Coil Surge Absorbing Function	Yes
Functions: Terminal Covers	No
Functions: Wiring Streamlining Terminal	No
Mounting Method	Screw Mounting
Terminal Screw Size: Main Circuit (Power Side)	M8
Terminal Screw Size: Main Circuit (Load Side)	M8
Terminal Screw Size: Operating Circuit	M4
Terminal Screw Size: Operation Coil	M4
