QD81DL96 Mitsubishi MELSEC-Q Series High speed data logger

MPN: QD81DL96 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSEC-Q Series – Information/network
Lifecycle	Active mature
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can QD81DL96 be shipped?

QD81DL96 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up QD81DL96 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for QD81DL96 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for QD81DL96, subject to availability and destination.

The Mitsubishi Electric QD81DL96 is a high speed data logger in the MELSEC-Q Series. 10BASE-T/100BASE-TX: 1 channel, data logging function, event logging function, report function, recipe function. Mitsubishi Electric has announced its discontinuation (2029/09 To be end of order) — plan spares now; PartnerPLC also sources it on the surplus market after the end of order. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC-Q Series
Category	High speed data logger
Sales status	2029/09 To be end of order (Mitsubishi Electric)
Outline	10BASE-T/100BASE-TX: 1 channel, data logging function, event logging function, report function, recipe function

Software specifications

Data sampling: Number of access target CPUs	Maximum of 64 CPUs
Data sampling: Data sampling interval: High speed data sampling	• Sequence scan time synchronization • 1...32767 ms (for trigger logging) • 3...32767 ms (for continuous logging)
Data sampling: Data sampling interval: General data sampling	• 0.1...0.9 s, 1...32767 s • Time interval specification (specify hour/minute/second)
Data sampling: Amount of sampled data: High speed data sampling	• Overall amount of data: maximum of 8192 (per setting: 256) • Overall number of device points: maximum of 8192 (per setting: 256)
Data sampling: Amount of sampled data: General data sampling	• Overall amount of data: maximum of 16384 (per setting: 256) • Overall number of device points: maximum of 262144 (per setting: 4096)
Data sampling: Data type	• Bit • Word (signed) • Double word (signed) • Word (unsigned) • Double word (unsigned) • Float (single precision) • Float (double precision) • 16 bit BCD • 32 bit BCD • String: 1 ... 8192 characters • Raw: 1 ... 8192 bytes
Data sampling: Data output format (CSV file)	• Bit • Decimal format: 0 to 14 digits after the decimal point • Exponential format: 0 to 14 digits after the decimal point • Hexadecimal format • String • Raw
Data sampling: Scaling	Basic arithmetic operations: calculations combining (*, /) and (+, -)
Data logging: Number of settings	Up to 64
Data logging: Logging type	• Continuous logging • Trigger logging
Data logging: File format	• CSV file (extension: CSV) • Binary file (extension: BIN)
Data logging: Period	Specify applicable period or exclusion period. • Data condition: bit ON/OFF, compare data to constant value, compare data to data • Date range: specify start and end with month and day. • Time range: specify start and end with hour, minute and second • Day of week/week condition: specify days of the week and weeks AND or OR combination of the above: up to 8 conditions
Data logging: Trigger logging: Trigger conditions	• Condition • Comparison: bit ON/OFF, compare data to constant value, compare data to data • At the time of change of value • Fixed cycle: 1...86400 s •Time interval specification: specify hour/minute/second • Time of day specification: specify month/day/hour/minute/second • At module startup AND or OR combination of the above: up to 8 conditions • Condition execution count: 3 conditions • Conditi
Data logging: Trigger logging: Number of logging lines	• Before trigger occurs: 0...65534 lines • After trigger occurs: 1...65535 lines The sum of lines of before and after trigger occurrence is up to 65535 lines.
Data logging: File switching timing	• Number of lines (number of records) specification: 100...100000 • File size specification: 10...16384K bytes • Condition specification • Comparison: bit ON/OFF, compare data to constant value, compare data to data • At the time of change of value • Fixed cycle: 1...86400 s • Time interval specification: specify hour/minute/second • Time of day specification: specify month/day/hour/minute/second
Data logging: Number of save files	1...65535
Event logging: Number of settings	Up to 64
Event logging: Number of events	Up to 64 events per single event logging setting
Event logging: File format	• CSV file (extension: CSV) • Binary file (extension: BIN)
Event logging: Event conditions	• Condition • Comparison: bit ON/OFF, compare data to constant value, compare data to data • At the time of change of value AND or OR combination of the above: up to 4 conditions • Condition execution count: 3 conditions • Condition execution order (order and/or time conditions): up to 4 conditions
Event logging: Period	Specify applicable period or exclusion period. • Data condition: bit ON/OFF, compare data to constant value, compare data to data • Date range: specify start and/or end month/day • Time range: specify start and/or end hour/minute/second • Day of week/week condition: specify days of the week and/or weeks AND or OR combination of the above: up to 8 conditions
Event logging: File switching timing	• Number of lines (number of records) specification: 100...100000 lines • File size specification: 10...16384K bytes • Condition • Comparison: bit ON/OFF, compare data to constant value, compare data to data • At the time of change of value • Fixed cycle: 1...86400 s • Time interval specification: specify hour/minute/second • Time of day specification: specify month/day/hour/minute/second • At mod
Event logging: Number of save files	1...65535
Report: Number of settings	Up to 64
Report: File format	Excel file (extension: xls)
Report: Output data type	• Data inside data logging file • Current value data • Creation time
Report: Amount of output data	64 layouts per single report setting, 65535 cells in total
Report: Creation trigger conditions	Condition: • Comparison: bit ON/OFF, compare data to constant value, compare data to data • At the time of change of value • Fixed cycle: 1...86400 s • Time interval specification: specify hour, minute and second • Time of day specification: specify month, day, hour, minute and second • At startup of module • At the time of the Data logging file is switched AND or OR combination of the above: up t
Report: Period	Specify applicable period or exclusion period. • Data condition: bit ON/OFF, compare data to constant value, compare data to data • Date range: specify start and/or end month/day • Time range: specify start and/or end hour/minute/second • Day of week/week condition: specify days of the week and/or weeks AND or OR combination of the above: up to 8 conditions
Report: Layout file size	Up to 10M bytes (total of all report settings)
Report: Number of save files	1...65535
E-mail: Application	• Notification when event occurs • Transmit saved file
E-mail: Subject	• Event notification e-mail: user specified • Saved file transmission e-mail: automatically created/user specified
E-mail: Body	• Event notification e-mail: user specified • Saved file transmission e-mail: automatically created/user specified
E-mail: Attachment	• Event notification e-mail: none • Saved file transmission e-mail: Saved file (CSV, binary, or Excel file), maximum of 512 KB
E-mail: Attachment format	MIME format
E-mail: MIME	Version 1.0
E-mail: Communication with mail server: Port number	25, 587, Others (1...65535)
E-mail: Communication with mail server: Authentication method	• No authentication • SMTP-AUTH (PLAIN, LOGIN, CRAM-MD5) • POP before SMTP
E-mail: Target address	Up to 16 groups
E-mail: Operability verified e-mail client software	• Microsoft ® Outlook ® Express 6.0 • Microsoft ® Windows ® Mail 6.0
FTP server: Application	Read and delete saved files Write, read, and delete recipe files
FTP server: Operability verified FTP client software	• Microsoft Edge ® • Windows ® Internet Explorer ® 11.0 • Windows ® Internet Explorer ® 10.0 • Windows ® Internet Explorer ® 9.0 • Windows ® Internet Explorer ® 8.0 • Windows ® Internet Explorer ® 7.0 • Microsoft ® Internet Explorer ® 6.0
FTP server: Session count	10
FTP client: Application	Transfer saved files
FTP client: Operability verified FTP server software	Microsoft ® Internet Information Services
Recipe: Number of data	Up to 256 data
Recipe: Number of records	Up to 256 records
Recipe: Data type	• Bit • Word [signed] • Double word [signed] • Word [unsigned] • Double word [unsigned] • FLOAT [single precision] • FLOAT [double precision] • 16bit BCD • 32bit BCD
Recipe: Recipe file	CSV file (extension: csv) Maximum of 256 files
Recipe: Execution type	Dedicated instructions (ladder program), configuration tool

Hardware specifications

Ethernet: Interface	10BASE-T, 100BASE-TX
Ethernet: Communication method	Full-duplex/half-duplex communication mode
Ethernet: Flow control	• Full-duplex: None (Does not support to the IEEE802.3x) • Half-duplex: Back pressure congestion control
Ethernet: Data transmission speed	10 Mbps (10BASE-T), 100 Mbps (100BASE-TX)
Ethernet: Transmission method	Base band
Ethernet: Number of cascaded connections	Maximum 4 stages (10BASE-T)/Maximum 2 stages (100BASE-TX)
Ethernet: Maximum segment length	100 m
Ethernet: Supported function	Auto-negotiation function (automatic recognition of communication speed/communication method)
CompactFlash card: Supply power capacity	Maximum 150 mA
CompactFlash card: Card size	TYPE I card
CompactFlash card: Supply power voltage	3.3 V ± 5 %
CompactFlash card: Number of installable cards	1
Number of occupied I/O points	32 points (I/O assignment: Intelligent 32 points)
Clock	• Acquired from a CPU module (in multiple CPU system, CPU No.1) or SNTP server • Time accuracy after obtaining the time is a daily variation of ±9.504 seconds
Internal current consumption (5 V DC)	0.58 A
External dimensions: Height	98 mm
External dimensions: Width	27.4 mm
External dimensions: Depth	90 mm
Weight	0.15 kg

Specifications

General specifications

Refer to the general specifications of the CPU module.

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

High Speed Data Logger Module User's Manual (SH-080818ENG-AA)	PDF · 12.72MB
GX LogViewer Version 1 Operating Manual (SH-080915ENG-AS)	PDF · 13.70MB
Operating Environment for GX LogViewer Version 1 (English Version) (BCN-P5879-D)	PDF · 0.07MB
