NZ2GF2B-60TCRT4 Mitsubishi MELSEC network modules Remote I/O

MPN: NZ2GF2B-60TCRT4 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSEC network modules – CC-Link IE Field
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can NZ2GF2B-60TCRT4 be shipped?

NZ2GF2B-60TCRT4 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up NZ2GF2B-60TCRT4 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for NZ2GF2B-60TCRT4 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for NZ2GF2B-60TCRT4, subject to availability and destination.

The Mitsubishi Electric NZ2GF2B-60TCRT4 is a remote I/O in the MELSEC network modules. 4 channels, platinum RTD (Pt100, JPt100), sampling cycle: 250 ms/4 channels, 500 ms/4 channels. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSEC network modules
Category	Remote I/O
Type	Analog I/O
Subtype	Temperature control
Outline	4 channels, platinum RTD (Pt100, JPt100), sampling cycle: 250 ms/4 channels, 500 ms/4 channels

Specifications

Control output	Transistor output
Number of temperature input points	4 channels/module
Applicable resistance temperature detector	Pt100, JPt100
Accuracy: Indication accuracy: Ambient temperature: 25±5 ˚C	Full scale × (±0.3 %)
Accuracy: Indication accuracy: Ambient temperature: 0...55 ˚C	Full scale × (±0.7 %)
Sampling cycle	250 ms/4 channels, 500 ms/4 channels
Control output cycle	0.5...100 s
Input impedance	1 MΩ
Input filter	0...100 s (0: Input filter OFF)
Sensor correction value setting	-50.00...50.00 %
Operation at sensor input disconnection	Up-scale processing
Temperature control method	PID ON/OFF pulse or two-position control
PID constants range: PID constants setting	Can be set by auto tuning.
PID constants range: Proportional band (P)	0.0...1000.0 % (0.0: Two-position control)
PID constants range: Integral time (I)	0...3600 s (set 0 for P control and PD control)
PID constants range: Derivative time (D)	0...3600 s (set 0 for P control and PI control)
Set value (SV) setting range	Within the temperature range set by the platinum resistance thermometer to be used.
Dead band setting range	0.1...10.0 %
Transistor output: Output signal	ON/OFF pulse
Transistor output: Rated load voltage	10...30 V DC
Transistor output: Maximum load current	0.1 A/point, 0.4 A/common
Transistor output: Maximum inrush current	0.4 A, 10 ms
Transistor output: Leakage current at OFF	0.1 mA or less
Transistor output: Maximum voltage drop at ON	1.0 V DC (TYP.) 0.1 A, 2.5 V DC (MAX.) 0.1 A
Transistor output: Response time: OFF to ON	2 ms or less
Transistor output: Response time: ON to OFF	2 ms or less
Isolation method	Between all power supply and communication system input terminals and all input terminals: Transformer, digital isolator Between input channels: Transformer, digital isolator Between all power supply and communication system terminals and all output terminals: Photocoupler
Dielectric withstand voltage	Between all power supply and communication system terminals and all input terminals: 500 V AC for 1 minute Between input channels: 500 V AC for 1 minute Between all power supply and communication system terminals and all output terminals: 500 V AC for 1 minute
Availability of connecting extension module	Not connectable
Station type	Remote device station
Cyclic transmission: RX/RY points	64 points
Cyclic transmission: RWr/RWw points	32 points
Module power supply: Voltage	24 V DC (20.4...28.8 V DC)
Module power supply: Current	230 mA (inrush current: 28.4 A, 1.5 ms or less)
External interface	Communication part: RJ45 connector Module power supply part: Terminal block for module power supply and FG (M2.5 screw) I/O part: 18-point two-piece terminal block (M3 screw)
Communication cable	An Ethernet cable that meets the 1000BASE-T standard: Category 5e or higher (double shielded, STP), straight cable
External dimensions: Height	65 mm
External dimensions: Width	160 mm
External dimensions: Depth	99 mm
Weight	0.35 kg

Specifications

Operating ambient temperature	0...55 ˚C
Storage ambient temperature	-25...75 ˚C
Operating ambient humidity	5...95 %RH, non-condensing
Storage ambient humidity	5...95 %RH, non-condensing
Vibration resistance: IEC 61131-2: 2007/JIS B 3502: 2011: Under intermittent vibration	Frequency: 5...8.4 Hz, Half amplitude: 3.5 mm Frequency: 8.4...150 Hz, Constant acceleration: 9.8 m/s 2 Sweep count: 10 times each in X, Y, and Z directions
Vibration resistance: IEC 61131-2: 2007/JIS B 3502: 2011: Under continuous vibration	Frequency: 5...8.4 Hz, Half amplitude: 1.75 mm Frequency: 8.4...150 Hz, Constant acceleration: 4.9 m/s 2
Shock resistance: IEC 61131-2: 2007/JIS B 3502: 2011	Three shocks in each direction per axis, on 3 mutually perpendicular axes (total of 18 shocks)
Operating atmosphere	No corrosive gases
Operating altitude	0...2000 m
Installation location	Inside a control panel
Overvoltage category	II or less
Pollution degree	2 or less
Equipment class	Class I

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

CC-Link IE Field Network Temperature Control Module User's Manual (SH-081211ENG-E)	PDF · 9.45MB
Before Using the Product (BCN-P5999-0064E-E)	PDF · 0.26MB
