HK-ST524WWS Mitsubishi MELSERVO servo MELSERVO-J5 series

MPN: HK-ST524WWS · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi MELSERVO servo – Rotary servo motors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can HK-ST524WWS be shipped?

HK-ST524WWS is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up HK-ST524WWS in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for HK-ST524WWS and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for HK-ST524WWS, subject to availability and destination.

The Mitsubishi Electric HK-ST524WWS is a MELSERVO-J5 series in the MELSERVO servo. 200 V: 1000 400 V: 2000 (1500). Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	MELSERVO servo
Category	MELSERVO-J5 series
Type	200 V AC 400 V AC
Outline	200 V: 1000 400 V: 2000 (1500)

Specifications

Series	MELSERVO-J5 series
Power class	200 V AC 400 V AC
Model name	HK-ST524WWS
Compatible servo amplifier *1	Refer to " Combinations of Rotary Servo Motors and Servo Amplifiers ".
Power supply capacity [kVA]	Refer to "Power Supply Capacity" for the power supply capacity in "MELSERVO-J5 catalog".
Continuous running duty *5: Rated output [kW]	200 V: 0.3 400 V: 0.5
Continuous running duty 5: Rated torque [N・m] 4 *6	200 V: 2.9 400 V: 2.4 (3.2)
Maximum torque [N・m] *4	200 V: 11.5 400 V: 7.2 (12.7)
Rated speed [r/min] 4 5	200 V: 1000 400 V: 2000 (1500)
Maximum speed [r/min] *5	200 V: 2000 400 V: 4000
Power rate at continuous rated torque [kW/s] *4	200 V: 13.9 400 V: 9.7 (17.2)
Rated current [A] *4	200 V: 1.8 400 V: 1.5 (2.0)
Maximum current [A] *4	200 V: 8.3 400 V: 5.1 (9.3)
Moment of inertia J [x 10 -4 kg・m 2 ]	5.90
Recommended load to motor inertia ratio *2	200 V: 15 times or less 400 V: 4 times or less *7 (When connected with MR-J5D, 19 times or less)
Speed・position detector	Batteryless absolute/incremental 26-bit encoder (resolution: 67,108,864 pulses/rev)
Type	Permanent magnet synchronous motor
Oil seal	None (Servo motors with an oil seal are available.)
Thermistor	None
Insulation class	155 (F)
Structure	Totally enclosed, natural cooling (IP rating: IP67) *3
Environment: Ambient temperature: Operation	0 °C to 60 °C (non-freezing) *20
Environment: Ambient temperature: Strage	-15 °C to 70 °C (non-freezing)
Environment: Ambient humidity: Operation	10 %RH to 90 %RH (non-condensing)
Environment: Ambient humidity: Strage	10 %RH to 90 %RH (non-condensing)
Environment: Ambience *19	Indoors (no direct sunlight); no corrosive gas, inflammable gas, oil mist or dust, no object generating a strong magnetic field
Environment: Altitude	2000 m or less *21
Environment: External magnetic field	10 mT or less
Environment: Vibration resistance *50	X: 24.5 m/s 2 ,Y: 49 m/s 2
Vibration rank	V10 *50
Satisfied standards	Refer to " Standards and certifications (by product) Products " for compliance with global standards and regulations.
Permissible load for the shaft *50: L [mm]	55
Permissible load for the shaft *50: Radial [N]	980
Permissible load for the shaft *50: Thrust [N]	490
Mass [kg]	5.0
