What is the Mitsubishi Electric HK-KT23G1 1/5?

The Mitsubishi Electric HK-KT23G1 1/5 is a MELSERVO-J5 series in the MELSERVO servo. 3000. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesMELSERVO servo
CategoryMELSERVO-J5 series
Type200 V AC
Outline3000

Specifications

SeriesMELSERVO-J5 series
Power class200 V AC
Model nameHK-KT23G1 1/5
Compatible servo amplifierRefer to " Combinations of Rotary Servo Motors and Servo Amplifiers ".
Power supply capacity [kVA]Refer to "Power Supply Capacity" for the power supply capacity in "MELSERVO-J5 catalog".
Continuous running duty *3: Rated output [kW]0.2
Continuous running duty *3: Rated torque [N・m] *40.64
Maximum torque [N・m]Refer to the following "Geared Servo Motor Specifications".
Rated speed [r/min] *33000
Maximum speed [r/min]Refer to the following "Geared Servo Motor Specifications".
Power rate at continuous rated torque [kW/s]19.4
Rated current [A]1.4
Maximum current [A]5.4
Moment of inertia J [x 10 -4 kg・m 2 ]Refer to the following "Geared Servo Motor Specifications".
Recommended load to motor inertia ratioRefer to the following "Geared Servo Motor Specifications".
Speed・position detectorBatteryless absolute/incremental 26-bit encoder (resolution: 67,108,864 pulses/rev)
TypePermanent magnet synchronous motor
Oil sealRefer to the following "Geared Servo Motor Specifications".
ThermistorNone
Insulation class155 (F)
StructureTotally enclosed, natural cooling (IP rating: IP67) *1 *5
Environment: Ambient temperature: Operation0 °C to 60 °C (non-freezing) *9
Environment: Ambient temperature: Strage-15 °C to 70 °C (non-freezing)
Environment: Ambient humidity: Operation10 %RH to 90 %RH (non-condensing)
Environment: Ambient humidity: Strage10 %RH to 90 %RH (non-condensing)
Environment: Ambience *8Indoors (no direct sunlight); no corrosive gas, inflammable gas, oil mist or dust, no object generating a strong magnetic field
Environment: Altitude2000 m or less *10
Environment: External magnetic field10 mT or less
Environment: Vibration resistance *50X: 49 m/s 2 ,Y: 49 m/s 2
Vibration rankV10 *50
Satisfied standardsRefer to " Standards and certifications (by product) Products " for compliance with global standards and regulations.
Permissible load for the shaft: L [mm]Refer to the following "Geared Servo Motor Specifications".
Permissible load for the shaft: Radial [N]Refer to the following "Geared Servo Motor Specifications".
Permissible load for the shaft: Thrust [N]Refer to the following "Geared Servo Motor Specifications".
Motor outer diameter (Flange size) [mm]Refer to the following "Geared Servo Motor Specifications".
Mass [kg]Refer to the following "Geared Servo Motor Specifications".

Specifications

Gear reducer: Servo motor model nameHK-KT23G1 1/5
Gear reducer: Output [kW]0.2
Gear reducer: Reduction ratio1/5
Gear reducer: Actual reduction ratio19/96
Gear reducer: Moment of inertia J [x 10 -4 kg・m 2 ] *130.363
Gear reducer: Permissible load to motor inertia ratio (when converted into the servo motor shaft) *147 times or less
Gear reducer: Oil sealNone
Gear reducer: Permissible load for the shaft *51: Q [mm]17.5
Gear reducer: Permissible load for the shaft *51: Radial [N]330
Gear reducer: Permissible load for the shaft *51: Thrust [N]350
Gear reducer: Mass [kg]3.2
Gear reducer: Lubrication methodGrease (filled)
Gear reducer: Mounting directionAny direction
Gear reducer: Mounting methodFlange mounting
Gear reducer: Output shaft rotating directionSame as the servo motor output shaft direction
Gear reducer: Backlash *1660 minutes or less at gear reducer output shaft
Gear reducer: Maximum torque *17Three times of the rated torque
Gear reducer: Maximum speed (at servo motor shaft)4500 r/min
Gear reducer: IP rating (gear reducer part)Equivalent to IP44
Gear reducer: Gear reducer efficiency *1540 % to 85 %
Gear reducer: Motor outer diameter (Flange size) [mm]90X90
