What is the Mitsubishi Electric ET-N60 60A?

The Mitsubishi Electric ET-N60 60A is a related Equipment in the Low-voltage switchgear. Adjustment Range of Setting Current : 0.25 to 1A. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineAdjustment Range of Setting Current : 0.25 to 1A

Specifications

Product SpecificationProtection Mode (1E/2E/3E)With Setting Switch
Rated Insulation Voltage Ui [V]660
Rated Operating Current [A]60
Range of Setting Current [A]15 to 60
Control Circuit Rated Operational Voltage: AC100V100 to 120V 50/60Hz
Control Circuit Rated Operational Voltage: AC200V200 to 240V 50/60Hz
Control Circuit Input [VA]: AC100V (AC100V Applied)7
Control Circuit Input [VA]: AC200V (AC200V Applied)14
Output Contact: Contact Arrangement1NO1NC
Output Contact: Rated Operating Current [A] Category AC-15: AC120V2
Output Contact: Rated Operating Current [A] Category AC-15: AC240V1
Output Contact: Reset MethodManual Reset
Protection Mode: Overload: Operating Current115±5%
Protection Mode: Overload: Operating Time (at 600% Current)3/5/7/15/30 Seconds
Protection Mode: Overload: Operating MethodHeat-Accumulating Operation (Inching/Hot Start Protection)
Protection Mode: Open Phase: Imbalance Sensitivity30 to 50%
Protection Mode: Open Phase: Operating Time3±1s
Protection Mode: Reverse-Phase: Operating MethodCurrent Detection
Protection Mode: Reverse-Phase: Operating Time0.5 or Less
Property Fluctuations As Voltage Fluctuates: Operating Current±5%
Property Fluctuations As Voltage Fluctuates: Operating Time±10%
Property Fluctuations As Temperature Fluctuates: Operating Current±5%
Property Fluctuations As Temperature Fluctuates: Operating Time±10%
Function: Trip DisplayYes
Function: Test TrippingYes
Function: Terminal CoversNo
Function: Wiring Streamlining TerminalNo
Mounting MethodScrew and DIN Rail Mounting
Terminal Screw Size: Main CircuitM5
Terminal Screw Size: Operating CircuitM3.5
