ET-N60 4A Mitsubishi Low-voltage switchgear Related Equipment

MPN: ET-N60 4A · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Related Equipment
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can ET-N60 4A be shipped?

ET-N60 4A is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ET-N60 4A in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ET-N60 4A and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ET-N60 4A, subject to availability and destination.

The Mitsubishi Electric ET-N60 4A is a related Equipment in the Low-voltage switchgear. Adjustment Range of Setting Current : 0.25 to 1A. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Outline	Adjustment Range of Setting Current : 0.25 to 1A

Specifications

Product Specification	Protection Mode （1E/2E/3E)With Setting Switch
Rated Insulation Voltage Ui [V]	660
Rated Operating Current [A]	4
Range of Setting Current [A]	1 to 4
Control Circuit Rated Operational Voltage: AC100V	100 to 120V 50/60Hz
Control Circuit Rated Operational Voltage: AC200V	200 to 240V 50/60Hz
Control Circuit Input [VA]: AC100V (AC100V Applied)	7
Control Circuit Input [VA]: AC200V (AC200V Applied)	14
Output Contact: Contact Arrangement	1NO1NC
Output Contact: Rated Operating Current [A] Category AC-15: AC120V	2
Output Contact: Rated Operating Current [A] Category AC-15: AC240V	1
Output Contact: Reset Method	Manual Reset
Protection Mode: Overload: Operating Current	115±5%
Protection Mode: Overload: Operating Time (at 600% Current)	3/5/7/15/30 Seconds
Protection Mode: Overload: Operating Method	Heat-Accumulating Operation (Inching/Hot Start Protection)
Protection Mode: Open Phase: Imbalance Sensitivity	30 to 50%
Protection Mode: Open Phase: Operating Time	3±1s
Protection Mode: Reverse-Phase: Operating Method	Current Detection
Protection Mode: Reverse-Phase: Operating Time	0.5 or Less
Property Fluctuations As Voltage Fluctuates: Operating Current	±5%
Property Fluctuations As Voltage Fluctuates: Operating Time	±10%
Property Fluctuations As Temperature Fluctuates: Operating Current	±5%
Property Fluctuations As Temperature Fluctuates: Operating Time	±10%
Function: Trip Display	Yes
Function: Test Tripping	Yes
Function: Terminal Covers	No
Function: Wiring Streamlining Terminal	No
Mounting Method	Screw and DIN Rail Mounting
Terminal Screw Size: Main Circuit	M5
Terminal Screw Size: Operating Circuit	M3.5
