DUD-N180 Mitsubishi Low-voltage switchgear Magnetic Contactor

MPN: DUD-N180 · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Low-voltage switchgear – Magnetic Contactors
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can DUD-N180 be shipped?

DUD-N180 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up DUD-N180 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for DUD-N180 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for DUD-N180, subject to availability and destination.

The Mitsubishi Electric DUD-N180 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 240A(Make contact 2-Pole Category DC2 DC110V) AC Operated For DC Road. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Low-voltage switchgear
Outline	Representative rating 240A(Make contact 2-Pole Category DC2 DC110V) AC Operated For DC Road

Specifications

Product Specification	AC Operated DC Contactor
Rated Insulation Voltage Ui [V]	660
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) Make Contact Single-Pole: DC110V	180
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) Make Contact Single-Pole: DC220V	120
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC110V	240
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC220V	180
Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC440V	120
Main Contact Conventional Free Air Thermal Current [A]	270
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V	6
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V	3
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V	1.5
Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V	1.2
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V	10
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V	8
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V	5
Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V	5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V	3
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V	1.5
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V	0.6
Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V	0.3
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V	10
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V	8
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V	5
Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V	1
Auxiliary Contact Conventional Free Air Thermal Current [A]	10
Auxiliary Contact Minimal Applicable Load	20V 3mA
Contact Arrangements (Valid): Main Contact (Standard)	2NO
Contact Arrangements (Valid): Auxiliary Contact (Standard)	2NO2NC
Mechanical Durability [Mil.Times]	250
Electrical Durability [Mil.Times]: Category DC2,DC4	50
Operation Coil Properties: Operating Voltage	DC Operated
Operation Coil Properties: Power Consumption [W]	41
Functions: Coil Surge Absorbing Function	No
Functions: Terminal Covers	No
Functions: Wiring Streamlining Terminal	No
Mounting Method	Screw Mounting
Terminal Screw Size: Main Circuit (Power Side)	M10
Terminal Screw Size: Main Circuit (Load Side)	M10
Terminal Screw Size: Operating Circuit	M4
Terminal Screw Size: Operation Coil	M4
