What is the Mitsubishi Electric DU-N260?
The Mitsubishi Electric DU-N260 is a magnetic Contactor in the Low-voltage switchgear. Representative rating 350A(Make contact 2-Pole Category DC2 DC110V) AC Operated For DC Road. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | Low-voltage switchgear |
| Outline | Representative rating 350A(Make contact 2-Pole Category DC2 DC110V) AC Operated For DC Road |
Specifications
| Product Specification | AC Operated DC Contactor |
| Rated Insulation Voltage Ui [V] | 660 |
| Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) Make Contact Single-Pole: DC110V | 260 |
| Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) Make Contact Single-Pole: DC220V | 175 |
| Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) Break Contact Single-Pole: DC110V | 150 |
| Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) Break Contact Single-Pole: DC220V | 100 |
| Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC110V | 350 |
| Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC220V | 260 |
| Main Contact Rated Operating Current [A]: DC Motor (Category DC2,DC4) 2-Pole: DC440V | 175 |
| Main Contact Conventional Free Air Thermal Current [A] | Make Contact :360 Break Contact :360 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V | 6 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V | 3 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V | 1.5 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V | 1.2 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V | 10 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V | 8 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V | 5 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V | 5 |
| Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC24V | 3 |
| Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC48V | 1.5 |
| Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V | 0.6 |
| Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC220V | 0.3 |
| Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V | 10 |
| Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC48V | 8 |
| Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC110V | 5 |
| Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC220V | 1 |
| Auxiliary Contact Conventional Free Air Thermal Current [A] | 10 |
| Auxiliary Contact Minimal Applicable Load | 20V 3mA |
| Contact Arrangements (Valid): Main Contact (Standard) | 2NO1NC |
| Contact Arrangements (Valid): Auxiliary Contact (Standard) | 2NO2NC |
| Mechanical Durability [Mil.Times] | 250 |
| Electrical Durability [Mil.Times]: Category DC2,DC4 | 50 |
| Operation Coil Properties: Operating Voltage | AC Operated |
| Operation Coil Properties: Inrush Input [VA] | 440 |
| Operation Coil Properties: Normal input [VA] | 50 |
| Operation Coil Properties: Power Consumption [W] | 6.1 |
| Functions: Coil Surge Absorbing Function | Yes |
| Functions: Terminal Covers | No |
| Functions: Wiring Streamlining Terminal | No |
| Mounting Method | Screw Mounting |
| Terminal Screw Size: Main Circuit (Power Side) | M12 |
| Terminal Screw Size: Main Circuit (Load Side) | M12 |
| Terminal Screw Size: Operating Circuit | M4 |
| Terminal Screw Size: Operation Coil | M4 |
