CD-25ANB Mitsubishi Power monitoring Current Transformers (CT)

MPN: CD-25ANB · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Power monitoring – Instrument Transformers
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can CD-25ANB be shipped?

CD-25ANB is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CD-25ANB in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CD-25ANB and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CD-25ANB, subject to availability and destination.

The Mitsubishi Electric CD-25ANB is a current Transformers (CT) in the Power monitoring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	Current Transformers (CT)
Type	Less than or equal to 6600V

Specifications

Category	Instrument Transformers
Group	Current Transformers (CT)
Circuit voltage	Less than or equal to 6600V
Use	For cubicle type high-voltage power receiving equipment
Model name	CD-25ANB
Rated primary current (A)	50
Secondary current (A)	5
Rated burden (VA)	25
Applicable standards	JIS C 4620 (Appendix)
Accuracy (class)	1PS
Rated withstand current (kA/s)	12.5・0.125
Highest voltage (V)	6900
Withstand voltage (kV)	22/60
Frequency (Hz)	Both 50/60
Mass (kg)	8.6

Specifications

Overcurrent trip system	If the relay trip system of a circuit breaker is a current transformer secondary current trip system, when a fault current is detected by the instantaneous element of the relay and is cut off, the large current in the secondary circuit of the current transformer will be cut off at contact point b of the relay and contact point b may be damaged. The risk of damage will be high; especially if the pr
Device combinations: Circuit breaker	VF-8□H-D/DG , VF-13□H-D/DG (equipped with overcurrent trip equipment)
Device combinations: Overcurrent trip relay	Static type , Model MOC-A1T-R
Device combinations: Current transformer: Rated burden	25VA
Device combinations: Current transformer: Model name	CD-25ANB
Device combinations: Current transformer: Rated primary current (*1)	50A
Current transformer applicable burden (VA) (*2)	10 to 25
Note	(1) When the primary current of current transformer is 40A or less, the voltage trip system (capacitor trip system) is recommended. (2) If the load used is less than the rated load, please use the T-100L load regulator (the load used can be adjusted to 2, 4, 6, or 8VA).

Specifications

Voltage trip system	The reliability of the overcurrent relay can be improved by using the voltage trip system (capacitor trip system) for the circuit breaker.
Device combinations: Circuit breaker （※3）	VF-8□H-D/DG , VF-8□M-D/DG , VF-13□H-D/DG , VF-13□M-D/DG (equipped with voltage trip equipment)
Device combinations: Overcurrent trip relay	Static type , Model MOC-A1V-R
Device combinations: Current transformer: Rated burden	25VA
Device combinations: Current transformer: Model name	CD-25ANB
Device combinations: Current transformer: Rated primary current	50A
Current transformer applicable burden (VA) (*4)	10 to 25
Note	(3) The part of the name shown by □ depends on the mounting method. (4) If the load used is less than the rated load, please use the T-100L load regulator (the load used can be adjusted to 2, 4, 6, or 8VA).

Specifications

Specifications	This load regulator should be used if the load for connected to the secondary circuit of the current transformer is below the range of applicable load required for the transformer (refer to the above tables). Be certain to use the load regulator for each phase (phase the current transformer is set for) and adjust the usage load to a value that is as close as possible to the rated load.
Rated current	5A
Load value adjustment	2, 4, 6 or 8VA (power factor 0.8)
Short-time current	800A/0.125sec
Withstand voltage	AC2000V 1min
