What is the Mitsubishi Electric CD-10ANB?

The Mitsubishi Electric CD-10ANB is a current Transformers (CT) in the Power monitoring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesPower monitoring
CategoryCurrent Transformers (CT)
TypeLess than or equal to 6600V

Specifications

CategoryInstrument Transformers
GroupCurrent Transformers (CT)
Circuit voltageLess than or equal to 6600V
UseFor cubicle type high-voltage power receiving equipment
Model nameCD-10ANB
Rated primary current (A)20
Secondary current (A)5
Rated burden (VA)10
Applicable standardsJIS C 4620 (Appendix)
Accuracy (class)1PS
Rated withstand current (kA/s)12.5・0.125
Highest voltage (V)6900
Withstand voltage (kV)22/60
Frequency (Hz)Both 50/60
Mass (kg)8.6

Specifications

Overcurrent trip systemIf the relay trip system of a circuit breaker is a current transformer secondary current trip system, when a fault current is detected by the instantaneous element of the relay and is cut off, the large current in the secondary circuit of the current transformer will be cut off at contact point b of the relay and contact point b may be damaged. The risk of damage will be high; especially if the pr
Device combinations: Circuit breakerVF-8□H-D/DG , VF-13□H-D/DG (equipped with overcurrent trip equipment)
Device combinations: Overcurrent trip relayStatic type , Model MOC-A1T-R
Device combinations: Current transformer: Rated burden10VA
Device combinations: Current transformer: Model nameCD-10ANB
Device combinations: Current transformer: Rated primary current (*1)20A
Current transformer applicable burden (VA) (*2)9 to 10
Note(*1) When the primary current of current transformer is 40A or less, the voltage trip system (capacitor trip system) is recommended. (*2) If the load used is less than the rated load, please use the T-100L load regulator (the load used can be adjusted to 2, 4, 6, or 8VA).

Specifications

Voltage trip systemThe reliability of the overcurrent relay can be improved by using the voltage trip system (capacitor trip system) for the circuit breaker.
Device combinations: Circuit breaker (※3)VF-8□H-D/DG , VF-8□M-D/DG , VF-13□H-D/DG , VF-13□M-D/DG (equipped with voltage trip equipment)
Device combinations: Overcurrent trip relayStatic type , Model MOC-A1V-R
Device combinations: Current transformer: Rated burden10VA
Device combinations: Current transformer: Model nameCD-10ANB
Device combinations: Current transformer: Rated primary current20A
Current transformer applicable burden (VA) (*4)5 to 10
Note(*3) The part of the name shown by □ depends on the mounting method. (*4) If the load used is less than the rated load, please use the T-100L load regulator (the load used can be adjusted to 2, 4, 6, or 8VA).

Specifications

SpecificationsThis load regulator should be used if the load for connected to the secondary circuit of the current transformer is below the range of applicable load required for the transformer (refer to the above tables). Be certain to use the load regulator for each phase (phase the current transformer is set for) and adjust the usage load to a value that is as close as possible to the rated load.
Rated current5A
Load value adjustment2, 4, 6 or 8VA (power factor 0.8)
Short-time current800A/0.125sec
Withstand voltageAC2000V 1min
