Kuka U636348

KR 210 R2700 extra incl. KR C4 EU

MPN: U636348
Category: High payload class

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Kuka U636348?

Kuka KR 210 R2700 extra incl. KR C4 EU, manufacturer part number U636348. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Rated payload	210 kg
Maximum reach	2696 mm
Mounting position	Floor
Pose repeatability (ISO 9283)	0.06 mm
Number of axes	6
Ambient temperature during operation	10 °C to 55 °C (283 K to 328 K)
Ambient temperature during stor./transp.	-40 °C to 60 °C (233 K to 333 K)
Protection rating (IEC 60529)	IP54
Prot. rating, in-line wrist (IEC 60529)	IP65
A1	123 °/s
A2	115 °/s
A3	112 °/s
A4	179 °/s
A5	172 °/s
A6	219 °/s
Height	1062.5
Depth	596 mm
Maximum number of servo axes	9
Rated supply voltage	AC 3x 380 V, AC 3x 400 V, AC 3x 440 V, AC 3x 480 V
Mains frequency	49...61 Hz
Mains side fusing	min. 3x 25 A slow-blowing, max. 3x 32 A slow-blowing, see rating plate
