Honeywell – VBF5011A1734/U VBF5011 and VBF5013 Flanged Control Ball Valves

The VBF5011 Two-Way and the VBF5013 Three-Way Control Ball Valve control hot and chilled water with glycol solutions up to 50% in heating, ventilating and air conditioning (HVAC) systems to provide two-position or modulating functions.

These valve can be used with Honeywell electronic actuators.

Features & Benefits:

Sizes from 2-1/2" to 6" with ANSI Class 125 flanged connections.

Equal percentage flow characteristic on 2-way valves 3-way A to AB port.

Can be used with Honeywell electronic actutors.

Field configurable for normally open or normally closed fail-safe position.

ANSI Class IV leakage specification (0.01% of CV) on 2-way valves and 3-way A to AB flow. ANSI Class III leakage on 3-way B to AB flow.

Wide range of CV choices from 63 to 360.

Mixing or diverting control available on 3-way valves.

Same flow pattern configuration as Globe valve.

Flange-to-flange dimensioning same as legacy V5011A/B and V5013B/C globe valves offering drop in replacement.

Honeywell VBF5011A1734/U — The VBF5011 Two-Way and the VBF5013 Three-Way Control Ball Valve control hot and chilled water with glycol solutions up to 50% in heating, ventilating and air conditioning (HVAC) systems. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
