Honeywell PIMRT00MI

INSERTIC CLASSIC MIFARE

MPN: PIMRT00MI
Category: Honeywell Access Control

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Honeywell parts? We buy surplus →

What is the Honeywell PIMRT00MI?

The "Insertic Classic" built-in readers are suitable for installation in standard flush-mounted switch boxes. Their

flat design means they protrude only 11 mm from the wall. Combined with their understated color scheme,

the readers blend harmoniously into both industrial and residential environments.

The reader's three LEDs (green, yellow, red) are controlled by the control panel during normal operation. Depending on the intrusion or access control panel used, the function is fixed or can be defined via programming.

The bright illuminated symbols and an integrated buzzer provide clear feedback during operation.

With the optional matching mounting frame, the reader can be individually mounted even without a flush-mounted box.

Features & Benefits:

Compact, slim design

Easy installation

Fits any flush-mounted or hollow-wall device box according to DIN with a device screw spacing of 60 mm

Suitable for outdoor and indoor use

Rear module with integrated interface:

Piezo buzzer

Switching regulator (8 to 30 V DC)

Connection terminals

Interface: RS485 module bus

MIFARE platform for cards and keyfobs

MIFARE DESFire EV1 / EV2 / EV3

MIFARE Classic

Honeywell PIMRT00MI — The Insertic readers complement the portfolio of readers that support the native RS-485 Modulbus of the ACS PRO and MB controllers via door modules. The more cost-effective Insertic Classic MIFARE readers support only MIFARE card technologies. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle

Active

Ordering codes

Part numbers on this product page

PIMRT00MI, PIMRT12MI
