Honeywell PIC00B.63

INSERTIC CLASSIC

MPN: PIC00B.63
Category: Honeywell Access Control

Price and lead time confirmed within 1 business day

Discontinued by Honeywell — we can still source the original PIC00B.63 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Honeywell parts? We buy surplus →

What is the Honeywell PIC00B.63?

The "Insertic Classic" built-in readers are suitable for installation in standard flush-mounted switch boxes. Their flat design means they protrude only 11 mm from the wall. Combined with their understated color scheme, the readers blend harmoniously into both industrial and residential environments.The reader is designed as a MIFARE reader by default, but can be switched to LEGIC technology via the ACS PRO controller or IQ-DeviceInstaller. Bluetooth technology can be enabled via the controller, allowing the reader to be used for mobile credentials.The reader's three LEDs (green, yellow, red) are controlled by the control panel during normal operation. Depending on the intrusion or access control panel used, the function is fixed or can be defined via programming.The bright illuminated symbols and an integrated buzzer provide clear feedback during operation. With the optional matching mounting frame, the reader can be individually mounted even without a flush-mounted box.

Features & Benefits:

Bluetooth® SIG certificate

Compact, slim design

Easy installation

Fits any flush-mounted or hollow-wall device box according to DIN with a device screw spacing of 60 mm

Suitable for outdoor and indoor use

Tamper detection

RFID, Bluetooth®, and Secure Element in one reader

Supports Mobile Access via LEGIC Neon Files

Rear module with integrated interface:

Piezo buzzer

Switching regulator (8 to 30 V DC)

Connection terminals

Dimensions (H x W x D): 81 x 81 x 24 mm

Interface: RS485 module bus

Firmware upgrade via module bus

Multi-ISO platform for cards and keyfobs

LEGIC prime/advant

MIFARE DESFire EV1 / EV2 / EV3

MIFARE Classic

ISO14443 A+B

ISO15693

Platforms for mobile credentials

Bluetooth Low Energy

NFC

Honeywell PIC00B.63 — The Insertic readers complement the portfolio of readers that support the native RS-485 Modulbus of the ACS PRO and MB controllers via door modules. The readers are Multi-ISO, supporting LEGIC and MIFARE card technology – and are Bluetooth ready. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle

Discontinued by Honeywell

Ordering codes

Part numbers on this product page

PIC00B.63, PIC00W.63, PIC12B.63, PIC12W.63
